VIGIL3 Audio Output Module
Verified by manufacturer 5 months ago
VIGIL3 audio output module, fits alongside the battery charger module.
Description
The VIGIL3 audio output module features eight individual audio outputs, two hard wired bypass inputs, five fire panel inputs, up to 24 band parametric EQ, one second audio delay and all EN54 mandatory fault indications.
Feature and benefits:
- Fully modular and expandable.
- Fast and responsive.
- Single point for configuration.
- No ethernet switches required.
- Programmable prioritization.
- Battery labelling: Yes.
- Connection ports: Various.
General information
Color | Black |
Finish | Powder-coated |
Material | Steel |
Shape | Rectangle |
Length | 311 mm |
Width | 60 mm |
Height | 70 mm |
Warranty description | Seven year Guidance for specification option: Baldwin Boxall warrants all product manufactured by itself for a period of seven years from date of invoice. |
Uniclass |
Specification data - Voice alarm controllers
Standard | To BS EN 54 and BS 5839. |
Rated voltage | 24 V.Manufacturer guidanceBattery voltage. |
Power amplifiers | |
Output voltage | 100 V line. |
Rated power output (per channel rms) | 75 W.150 W.300 W.Manufacturer guidanceVarious. |
Overall efficiency (minimum) | 0.9. |
Frequency response at rated power output | 35 Hz to 20 kHz. |
Ventilation | Yes. |
Emergency message generators | |
Number of pre-recorded messages | 254. |
Languages | Any. |
Messages | Flash PROM (non volatile). |
Connection ports | |
Audio inputs | DSP. |
Audio outputs | Supports up to 800 outputs. |
Controls | |
Features | No limit. |
Display type | LED and LCD. |
Event log | Yes. |
Battery charger | |
Standard | To BS EN 54. |
Operation | 27.35 V.Manufacturer guidanceBattery charger operation |
Controls | |
Display type | LEDs mounted on front panel. |
Display the following conditions | Supply, OK, Batt Hi Res, Batt Low Volt, Charger and fuse. |
Enclosure | |
Material | Steel. |
Finish | Powder coated. |
Colour | Black. |
Ingress protection (minimum) | IP30.Guidance for specification option: As a system. |
Mounting method | Wall. |
Channels | Supports up to 64 simultaneous audio channels. Manufacturer guidanceAudio channels |
Type | Lead acid. Manufacturer guidanceBattery type |
Battery capacity | Guidance for specification option: Various. |
Modules | Supports up to 100 modules per system. Manufacturer guidanceModules per system |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | Revit 2017 | 1 |
