CLD Dulok Security Fence - Security Fence

Name: CLD Dulok Security Fence - Security Fence
Brand: CLD Physical Security Systems
SKU: oAogc48fNuT8kTVHAVch5D

Verified by manufacturer 2 days ago

CLD Physical Security Systems

Mesh and double wire flat panel fencing system.

Jump to:

BOS

+44 (0)1270 764751 Website

Application

The CLD Dulok mesh fencing system is a robust and adaptable solution, ideal for securing a wide range of environments where visibility, durability, and aesthetics are key. Designed with twin horizontal wires welded either side of a strong vertical wire, Dulok offers enhanced resistance to cutting and intrusion—making it a trusted choice for public and high-traffic areas.

Available in two configurations—868 (6 mm verticals with twin 8 mm horizontals) and 656 (5 mm verticals with twin 6 mm horizontals)—Dulok can be tailored to meet varying levels of security and aesthetic needs.

This makes Dulok particularly suitable for:

Public buildings
Schools and educational facilities
Industrial buildings
Zoos and animal enclosures
Sport facilities

Offering extremely high anti cut-through resistance, a wide range of height options, and the ability to add cranked or straight extensions for barbed or razor wire, Dulok ensures a secure perimeter without compromising visual appeal. It is also available in the full RAL colour range to match site branding or blend with surroundings.

Whether it's protecting school grounds or enclosing an industrial site or zoo habitat, CLD Dulok delivers reliable performance with long-term visual impact.

Description

CLD Dulok is a highly versatile mesh fencing system, which offers an aesthetic and cost-effective solution where visibility is required. Dulok features twin horizontal wires either side of the vertical wire. It is available in two different options: 6 mm verticals and twin 8 mm horizontals, or 5 mm verticals and twin 6 mm horizontals (traditionally known as 868 and 656).

Features and benefits:

Extremely high, anti cut-through, double wire panels.
Wide range of height options.
Cranked or straight extensions for barbed and razor wire.
RAL colours available.

General information

Color	Green Other Guidance for specification option: Any RAL colour available.
Finish	Powder-coated Galvanized
Material	Steel
Shape	Rectangle
Width	2506 mm
Height	Bespoke Guidance for specification option: 630-6060 mm.
Warranty description	15 year Guidance for specification option: Minimum of 15 years against manufacturing defects.

Uniclass	Ss_25_14_61_51 Metal mesh panel fencing systemsPrimary
CAWS	Q40/27 Open mesh steel panel general-purpose fencing Q40/30 Proprietary fencing Q40/430 Proprietary fencing

Product range	Perimeter Security Systems

Specification data - Metal mesh panel fencing systems

System performance	Anti-intruder and security fencing performance.
Standard	To BS 1722-14:2017, BS EN ISO 1461:2009, BS EN 13438:2013.
Posts	Carbon steel posts. Guidance for specification option: RHS. Manufacturer guidance Galvanized after manufacture and polyester powder-coated to match fencing.
Post foundations	Set posts in holes minimum 300 mm diameter x 800 mm deep.
Panels	Mesh and wire, single vertical and double horizontal wires. Dulok Sports Rebound system panel type. Guidance for specification option: Available on request, contact manufacturer for details.
Fence topping	Cranked. Straight. Manufacturer guidance For barbed and razor wire depending on panel height.
Site applied finishes	Polyester powder-coated to 60-80 µ. Polyester powder-coated to 160-200 µ. Manufacturer guidance With marine grade and metallics.

Height	Guidance for specification option: Available heights between 630–6060 mm. Insert requirements. Post dimensions 60 mm x 40 mm to 120 mm x 60 mm depending on height of panel. Manufacturer guidance Fence heights above 3030 mm are made up of two or more panels.
Colour and finish	Green. Guidance for specification option: As standard. RAL colour. Guidance for specification option: Consult manufacturer and insert requirement.
Fixing	40 x 5 mm full length clamp bar. M8 x 40 mm stainless steel pin hex dome-head security screws. Guidance for specification option: Sheardrive™ if required instead of pin hex.
Width	2506 mm.
Mesh size	200 x 50 mm.
WireDiameter	6 mm verticals and twin 8 mm horizontals (868). 5 mm verticals and twin 6 mm horizontals (656).
Projection	30 mm. Manufacturer guidance Top edge projection.
Installation	Bottom of panel approximately 40 mm above ground.
Size	80 x 40 mm. 120 x 60 mm. Manufacturer guidance Depending on height of panel.
Post centres	2520 mm.
