Bauder Bitumen Vertical Refurb Rainwater Outlets with Stainless Steel Leaf Guard and Mechanical Seal - Stainless-Steel Rainwater Outlet

Name: Bauder Bitumen Vertical Refurb Rainwater Outlets with Stainless Steel Leaf Guard and Mechanical Seal - Stainless-Steel Rainwater Outlet
Brand: Bauder Ltd
SKU: johN3ysRFWk9WWGFbJcLst

Verified by manufacturer 4 days ago

GB14120290 - DN145

Bauder Ltd

Stainless-steel rainwater outlet with vertical spigot, factory bonded membrane flange, stainless steel leaf guard and mechanical seal for refurbishment roof scenarios.

Jump to:

Request BIM

+44 (0)1473 257671 Website

Application

For use with Bauder bituminous waterproofing membranes when connecting into conventional gravity drainage systems.
The product is designed to be used in refurbishment roof scenarios.
The spigot when fitted into an existing outlet using the mechanical seal, will accommodate internal diameters ranging from 73 to 168 mm (depending on product choice).

Description

A stainless-steel rainwater outlet with vertical spigot. Factory bonded membrane flange attached to the outlet allows for ease of installation. Also supplied with a stainless steel leafguard and mechanical seal.

Features and benefits:

Factory bonded membrane flange attached to the outlet for ease of installation.
Supplied with stainless steel leafguard and mechanical seal.
Flow rate performance based on BS EN 12056:3:2000.

General information

Color	Grey
Finish	Other
Material	Stainless steel Guidance for specification option: Spigot. Bitumen Guidance for specification option: Membrane flange. (Bitumen bottom, Mica finish top surface)
Shape	Circle Square
Length	400 mm Guidance for specification option: Length of outlet including spigot. 500 mm Guidance for specification option: Bitumen flange.
Width	500 mm Guidance for specification option: Bitumen flange.
Height	2.7 mm Guidance for specification option: Height/Thickness of Bitumen Flange
Warranty description	- Manufacturer guidance A comprehensive range of guarantee options are available. Please contact your local Bauder Area Technical Manager for more information. To be supplied as part of a full Bauder Waterproofing System only.

Uniclass	Pr_65_50_35_37 Gravity rainwater outletsPrimary
CAWS	R10/26 Proprietary rainwater outlets R10/365 Proprietary rainwater outlets

SKU Code	GB14120290

Specification data - Gravity rainwater outlets

Classification data
Roof construction	-
Form	- Manufacturer guidance Insert requirements.
Roof insulation thickness	- Manufacturer guidance Insert requirements.
Material	Stainless steel.
Grating	Domed. Guidance for specification option: Stainless steel leaf-guard. 210 x 210 x 43 mm. To suit pipe diameter 50–160 mm. Weight: 0.28 kg.
Spigots	400 mm, stainless steel spigot.
Integral accessories	Mechanical seal tightening tool. Guidance for specification option: GB14120300. 70 mm wide. 105 mm total length, 50 into outlet. To suit existing pipe diameter 73–84 mm. Weight: 0.25 kg.
Diameter	DN145.
Flange	Bitumen bottom surface, mica top surface. Guidance for specification option: 500 x 500 mm. 2.7 mm.
Flow rate	5.48 L/sec. Guidance for specification option: *Flow rate performance data using a 35 mm head of water (including leaf guard), based upon requirements of BS EN 12056:3:2000. Further flow rate performance data can be obtained within this document. For bespoke drainage calculation performance data, please contact Bauder Limited.
Weight	2.3 kg.

Sustainability data

Material	Stainless steel Guidance for specification option: Spigot. Bitumen Guidance for specification option: Membrane flange. (Bitumen bottom, Mica finish top surface)
