Heavy, Severe Duty Non-Fire Rated Doorsets
Verified by manufacturer 4 months ago
Heavy, severe duty doors.
Application
Suitable for heavy-duty use in non-fire rated applications.
Description
Heavy, severe duty doors.
Features and benefits:
- Constructed from a solid laminate timber core, available in 44 mm and 54 mm thickness.
- Available with FSC/ PEFC certification - consult manufacturer for details.
- Two types of frame construction are supplied:
- Solid rebated frame with integral stop - main section 94 x 44 mm (finished). Extensions can be fitted for wall depths up to 200 mm.
- Planed square edge (PSE) section with loose door stops - 32 mm up to 125 mm solid (one piece) with a 32 x 13 mm stop. For wall depths in excess of 125 mm a tongued extension piece is fitted.
- Frames can be softwood or hardwood to suit project requirements.
- Architrave: Three profile types as standard, other profile types and sizes can be supplied to requirements.
- Royd and Tucker Hi-Load H105 lift off hinges with 25 year guarantee.
- Bridgman are members of the Exova/ BM Trada Q Mark Scheme.
General information
Shape | Rectangle |
Finish | Primed Guidance for specification option: Factory primed. Laminated Lacquered Manufacturer guidanceAlso available with a Hygienilac finish. |
Material | Wood |
Warranty description | 25 year Guidance for specification option: Royd and Tucker Hi-Load H105 lift off hinges with 25 year guarantee. |
Uniclass | |
CAWS | L20/410 Wood doorsets L20/55 Doorsets |
Specification data - Wood doorsets
Third party accreditation | FSC/ PEFC certification.Guidance for specification option: Consult manufacturer for details. |
Configuration | Single leaf, single action. |
Format | Single leaf, single action. |
Frame | |
Material | Hardwood.Softwood. |
Finish | Factory primed.Hygienilac.Laminated.Lacquered. |
Door leaf | |
Thickness | 44 mm.54 mm. |
Core | Solid timber. |
Facings | Laminated.Medium density fibreboard (MDF).Plywood.Veneered.Acrovyn. |
Lippings | Hardwood. |
Finish | Factory primed.Hygienilac.Laminated.Lacquered. |
Glazing | |
Type | Vision panel. |
Door accessories | Not required.Kick plates.Guidance for specification option: Consult manufacturer for details. Mouldings.Guidance for specification option: Consult manufacturer for details. Overpanels.Guidance for specification option: Consult manufacturer for details. Push plates.Guidance for specification option: Consult manufacturer for details. Factory mortising for locks.Guidance for specification option: Consult manufacturer for details. Slots for letter plates.Guidance for specification option: Consult manufacturer for details. Water bar rebates.Guidance for specification option: Consult manufacturer for details. |
Planted stops | |
Wood species | Hardwood.Softwood. |
Architraves | Type 1. Type 2. Type 3. |
Type | Solid rebated frame with integral stop. Guidance for specification option: Main section 94 x 44 mm (finished). Extensions can be fitted for wall depths up to 200 mm. Planed square edge (PSE) section with loose door stops. Guidance for specification option: 32 mm up to 125 mm solid (one piece) with a 32 x 13 mm stop. For wall depths in excess of 125 mm a tongued extension piece is fitted. Manufacturer guidanceDoor frame type. |
