Education Range: Music Room Doorset

Name: Education Range: Music Room Doorset
Brand: Bridgman IBC Ltd
SKU: hmn3RLnxJjAAZSkxcGoyNY

Verified by manufacturer 2 months ago

Third party certifications:

A severe duty, single music room doorset with one vision panel.

Jump to:

Application

A doorset suitable for classrooms and education facilities, specifically for music rooms.

A severe duty, single music room doorset with one vision panel.

Features and benefits:

The severe duty flax core doors (framed) are available in 44 mm and 54 mm thickness.
Two types of frame construction are available:
Solid rebated frame with integral stop - main section 94 x 44 mm (finished). Extensions can be fitted for wall depths up to 200 mm.
Planed square edge (PSE) section with loose door stops - 32 mm up to 125 mm solid (one piece) with a 32 x 13 mm stop. For wall depths in excess of 125 mm a tongued extension piece is fitted.
Frames can be softwood or hardwood to suit project requirements.
Architrave: Three profile types as standard, other profile types and sizes can be supplied to requirements.
Bridgman are members of the Exova/ BM Trada Q Mark Scheme.

Finish	Primed Lacquered Laminated Manufacturer guidance Also available with Hygienilac finish.
Material	Wood
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	25 year Guidance for specification option: On hinges.

Uniclass	Pr_30_59_24_97 Wood doorsetsPrimary
CAWS	L20/410 Wood doorsets L20/55 Doorsets

Third party accreditation	FSC; PEFC certification. Guidance for specification option: Consult manufacturer for details.
Configuration	Single leaf, single action.
Doorset size	1000 x 2100 mm.
Format	Single leaf, single action.
Frame	-
Material	Hardwood. Softwood.
Finish	Factory primed. Hygienilac. Lacquered. Laminated.
Frame accessories	Not required. Cookes Brothers butt hinges. Royd and Tucker hi-load H105 lift off hinges. Union 603 butt hinges.
Door leaf	-
Thickness	44 mm. 54 mm.
Facings	Acrovyn. Laminated. Medium density fibreboard (MDF). Plywood. Veneered.
Finish	Factory primed. Hygienilac. Lacquered. Laminated.
Door accessories	Not required. Kick plates. Guidance for specification option: Consult manufacturer for details. Mouldings. Guidance for specification option: Consult manufacturer for details. Overpanels. Guidance for specification option: Consult manufacturer for details. Push plates. Guidance for specification option: Consult manufacturer for details. Alarm wiring facilities. Guidance for specification option: Linked to existing alarm systems, consult manufacturer for details. Emergency exit facilities. Guidance for specification option: Consult manufacturer for details. Factory mortising for locks. Guidance for specification option: Consult manufacturer for details. Fire resisting doors. Guidance for specification option: Consult manufacturer for details.
Architraves	-
Wood appearance class	Type 1. Type 2. Type 3.

Lippings	Hardwood.
Type	Solid rebated frame with integral stop. Guidance for specification option: Main section 94 x 44 mm (finished). Extensions can be fitted for wall depths up to 200 mm. Planed square edge (PSE) section with loose door stops. Guidance for specification option: 32 mm up to 125 mm solid (one piece) with a 32 x 13 mm stop. For wall depths in excess of 125 mm a tongued extension piece is fitted.
