GLV-11 Solid Steel Roller Shutter (Galvanised) - Roller Shutter
Verified by manufacturer 5 months ago
GLV-11 Manual
GLV-11 Manual
Our galvanized steel roller shutters, made from 22swg steel, can be upgraded to 20swg or 18swg for greater security. Available with powder-coating, perforation, or punching for a tailored finish.
Application
Suitable uses include:
- Warehouses.
- Factories.
- Large apertures (openings in excess of 16 m²).
- Industrial units.
- Commercial units.
Description
These galvanized steel shutters are very versatile as many features can be added or taken away to suit specifier needs and budget. For example, a shutter can be made from thicker steel, made with extra windlocks, have brush strips and rubber added, powder coated or plastisol coated to a wide variety of RAL colours and much more. Punched (GLV-11PU) and perforated (GLV-11PE) slats can be incorporated as required for full or partial vision.
Features and benefits:
- Can be upgraded to Secure By Design Status or LPS1175 Security ratings 1-4.
- Can be powder coated or plastisol coated to any RAL colour.
- Can be made from 18, 20, or 22swg as standard and any other gauge if requested.
- Wicket access doors can be incorporated into the shutter if needed.
- Protection against crushing, shearing or drawing in.
- Fully CE marked.
General information
Color | Grey Other Guidance for specification option: Any RAL or BS colour. Insert requirements. |
Finish | Galvanized Plastisol Powder-coated |
Material | Steel |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | One year Guidance for specification option: On electrical parts. |
Uniclass | |
CAWS | L20/60 Doors L20/610 Roller shutters/ curtains |
Specification data - Roller shutters
Opening sizes | Manufacturer guidanceBespoke, available on request. |
Format | External. |
Arrangement | Vertical. |
Performance | |
Resistance to wind load | Class 2. |
Shutter curtain. | |
Lath material | Galvanized steel. |
Profile | Curved. |
Finish and colour | Galvanized, self-colour.Guidance for specification option: Non-galvanised parts prime painted as standard. Polyester powder coated, BS.Polyester powder coated, RAL. |
Frame and guides | |
Material | Steel. |
Finish | Galvanized.Polyester powder coated.Plastisol. |
Colour | BS.RAL.Self-colour. |
Operation | |
Mode | Manual. |
Control | Spring and lock.Guidance for specification option: For smaller shutters. Belt cord.Guidance for specification option: For smaller shutters. Hand chain.Guidance for specification option: For larger shutters. |
Battery back-up | Not required. Required. |
Steel grade | 0.7 mm (22 swg). 0.9 mm (20 swg). 1.2 mm (18 swg). |
Bottom rail design | Galvanizsed and roll-formed into a tee section. |
End plates | Mild steel. Guidance for specification option: Of appropriate thickness in relation to door thickness is prime painted and supplied with angles for fixing to he structure. |
Barrel | Seamless steel tube. Guidance for specification option: Of adequate diameter to counteract deflection and hold in bearings or cups attached to the endplates. |
Dimensions | 2500 x 305 mm. 4000 x 355 mm. 5500 x 400 mm. Manufacturer guidanceEnclosure dimensions: shutter height (up to mm) x box size. The enclosure sizes are based on standard tube mortar operation. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Steel |
Manufacturing plant location | |
Recyclability | Mostly recyclable as 95% of the product is steel |
Expected Life | 30 year |
Literature
GLV-11 Brochure
