ALU-12M411 Insulated Aluminium Roller Shutter - Roller Shutter
Verified by manufacturer 4 months ago
ALU-12M411 Electric
ALU-12M411 Electric
Aluminium double skinned polyester powder coated shutter with polyurethane foam insulating core.
Application
Low to medium security domestic sites with a maximum size of 8 m². Suited to windows and doors to block out light, cold and sound, including:
- House windows.
- Office windows.
- Reception counters.
- Display areas.
Description
Aluminium roller shutter that combines heat and sound control with aesthetics. Made from 43 mm insulated aluminium, the shutters can be programmed to run from a variety of control methods including remote controls, switches or even a smartphone.
If security is more important, the ALU-1237 model may be more appropriate and for larger openings see the ALU-12M511 model.
Features and benefits:
- Offers low to medium security.
- Traditionally offers a more cost effective and aesthetically pleasing solution to that of an insulated steel shutter.
- Lighter than a steel shutter means less energy is needed to open them (4 kg/m²).
- Fully CE marked.
- Protection against crushing, shearing or drawing in.
General information
Color | White Brown Cream Green Grey |
Finish | Powder-coated Guidance for specification option: Polyester powder coated. |
Material | Aluminium |
Shape | Rectangle |
Warranty description | One year Guidance for specification option: On electrical parts. |
Uniclass | |
CAWS | L20/60 Doors L20/610 Roller shutters/ curtains |
Specification data - Roller shutters
Opening sizes | Manufacturer guidanceBespoke, available on request. |
Format | Thermally insulated. |
Arrangement | Vertical. |
Performance | |
Resistance to wind load | Class 2. |
Shutter curtain. | |
Lath material | Aluminium.Guidance for specification option: Aluminium double skinned polyester powder coated slat with polyurethane foam insulating core. |
Finish and colour | Polyester powder coated, black.Guidance for specification option: RAL 9005. Available for an additional cost. Polyester powder coated, brown.Guidance for specification option: RAL 8019. Polyester powder coated, cream.Guidance for specification option: RAL 9001. Polyester powder coated, fir green.Guidance for specification option: RAL 6009. Polyester powder coated, grey.Guidance for specification option: RAL 7038. Polyester powder coated, silver.Guidance for specification option: RAL 9006. Polyester powder coated, white.Guidance for specification option: RAL 8019. Manufacturer guidanceStandard curtain colours. Available in vented and non-vented options. |
Frame and guides | |
Material | Aluminium. |
Finish | Powder coating. |
Colour | Black.Brown.Cream.Fir green.Grey.Silver.White.RAL/BS colour.Guidance for specification option: Box and guides can be powder coated to any stocked RAL/BS colour for an additional charge. |
Operation | |
Mode | Automatic, single-phase tubular motor. |
Control | Wall switch.Guidance for specification option: As standard. Manual override facility as required. Key switch.Radio/remote Control.Rocker switch.Timer closing.Loop and Radar operation.Smart phone.Swipe Card activation.Automated.Other.Guidance for specification option: UK Roller Shutters Ltd can access anyone's systems for operation. Manufacturer guidanceNot all options are available on all size shutters. |
Face | 4 kg. Manufacturer guidanceCurtain slat visible face. |
Weight | 4 kg/m². Manufacturer guidanceCurtain slat weight per m². |
Width | 3400 mm. Manufacturer guidanceCurtain slat maximum width. |
Surface | 8 m². Manufacturer guidanceCurtain slat maximum surface. |
U-value | 3.7 W/m²K. Manufacturer guidanceCurtain slat. |
Guide channels depth | 45 mm. 53 mm. 60 mm. 66 mm HD. Guidance for specification option: Heavy duty. |
Material | Extruded aluminium with brush inserts. Manufacturer guidanceGuide channels material. |
Bottom slat | Extruded aluminium with rubber weather seal. |
Curtain type | Non-vented. Guidance for specification option: Solid version. Vented. Guidance for specification option: Allows small amounts of light and air in if required. |
Hood/ fascia | Not required. Circular option for canopy. Guidance for specification option: If required. |
Sustainability data
Country of product manufacture | United Kingdom |
Literature
ALU-12M411 Brochure
ALU-12M411 Drawings_datasheet
