Verified by manufacturer 1 month ago
GLV-11 PU Electric
Punched steel shutter.
Suitable uses include:
These punched galvanized steel shutters have rectangular holes punched into them allowing 32% visibility and air flow making them ideal for shop fronts or car parks. The holes can be arranged in an in-line or brick-bond formation, depending on requirements. They can also be incorporated with solid lath to create a mixed effect. There are many features that can be added or taken away to suit specifier needs and budget. The shutter can be made from thicker steel, made with extra windlocks, have brush strips and rubber added, powder coated or plastisol coated to a wide variety of RAL colours.
Features and benefits:
Color | Grey Other Guidance for specification option: Any RAL or BS colour. Insert requirements. |
Finish | Galvanized Plastisol Powder-coated |
Material | Steel |
Shape | Rectangle |
Warranty description | One year Guidance for specification option: On electrical parts. |
Uniclass | |
CAWS | L20/60 Doors L20/610 Roller shutters/ curtains |
Opening sizes | Manufacturer guidanceBespoke, available on request. |
Format | External. |
Arrangement | Vertical. |
Performance | |
Resistance to wind load | Class 2. |
Shutter curtain. | |
Lath material | Galvanized steel. |
Profile | Curved, punched. |
Finish and colour | Galvanized, self-colour.Polyester powder coating, BS colour.Polyester powder coating, RAL colour. |
Frame and guides | |
Material | Steel.Guidance for specification option: Rolled steel or fabricated dependent on size and are supplied with appropriate angles for fixing to the structure. |
Finish | Galvanized.Polyester powder coated.Plastisol. |
Colour | BS.Guidance for specification option: Insert requirements. RAL.Guidance for specification option: Insert requirements. Self-colour. |
Operation | |
Mode | Automatic, 3-phase outboard motor.Guidance for specification option: 400-volt (larger shutters). Automatic, single-phase tubular motor.Guidance for specification option: 240-volt (smaller shutters). |
Control | Key switch.Remote control.Rocker switch.Smart phone.Automated.Other.Guidance for specification option: UK Roller Shutters Ltd can access anyone's systems for operation. Consult manufacturer. Manufacturer guidanceNot all options are available on all size shutters - consult manufacturer. |
Battery back-up | Not required. Required. |
Steel grade | 0.7 mm (22 swg). 0.9 mm (20 swg). 1.2 mm (18 swg). |
Air flow | 32%. Manufacturer guidanceVisibility and airflow. |
End plates | Mild steel. Guidance for specification option: Prime painted and supplied with angles for fixing to he structure. |
Barrel | Seamless steel tube. Guidance for specification option: Adequate diameter to counteract deflection and hold in bearings or cups attached to the endplates. |
Dimensions | 2500 x 305 mm. 4000 x 355 mm. 5500 x 400 mm. Manufacturer guidanceEnclosure size: shutter height (up to mm) x box size. Based on standard tube motor operation. |
Country of product manufacture | United Kingdom |
