Deckshield Rapide ID System - MMA Intermediate Car Park Deck Coating

Verified by manufacturer 9 months ago

Flowcrete – a brand of Tremco CPG UK Ltd Third party certifications:
  • Indoor Air Comfort – Eurofins

    Indoor Air Comfort – Eurofins

    Certificate type

Solvent-free fast cure methyl methacrylate (MMA) car park deck coating system for use on intermediate car park decks.

Jump to:
BIM object icon
+44 (0)1942 251400 Website

Application

Suitable for refurbishment of existing car parks and on new construction projects.

IMPORTANT: All specification information must be checked against the individual site requirements. Flowcrete advises that specifications are confirmed with their technical experts.

Description

Methyl methacrylate (MMA) car park deck coating system for use on intermediate car park decks.

Developed to enable fast track applications and reduce downtime, and has bond strength.


Features and benefits:

  • Fast cure.
  • Slip resistant.
  • Solvent free.
  • Aesthetically attractive.
  • Heavy duty.
  • Reduces noise.
  • Water resistant.

General information

Color

Blue

Green

Grey

Purple

Red

Finish

Satin

Matt

Material

Methyl methacrylate

Methyl methacrylate resin and fillers.


Warranty description

Ten year

Uniclass

Ss_30_42_54_75 Resin flooring systemsPrimary

CAWS

M12/10 Resin flooring

M12/110 Resin flooring

Specification data - Resin flooring systems

Substrate

-

Testing

Concrete or screed substrate should be a minimum of 25 N/mm², free from laitance, dust and other contamination and should be dry to 95% RH as per BS8204.

Primer

Flowfast Damp Primer with natural quartz.

Resin flooring

Deckshield Rapide ID.

For normal wear areas e.g. parking bays and lighter traffic.

Comprises Flowfast flexible binder with SNL filler, natural quartz and Deckshield Rapide topcoat.

Deckshield Rapide ID-HD.

For heavier wear areas e.g. drive aisles, turning points and ramps.

Deckshield Rapide ID-Ramp.

For very heavy wear areas e.g. sole entry/ exit ramps and turning points.

Colour options

Dark Grey.

Forest Green.

Mid Grey.

Tile Red.

Traffic Blue.

Show more

Retroflectivity

Not required.

Required.

Consult manufacturer for details.

Thickness range

3–4 mm.

Certification

CE Marked; Tested & certified to OS8 and EN 1504-2.

Uses

Intermediate decks of multi-storey car parks.

Bond strength

To UNE-EN 1542:1999: >1.5 MPa.

Measurement of bond strength by pull-off.

Water vapour transmission

To UNE-EN ISO 7783:2012, Class II: 5 ≤ Sd ≤ 50 m.

Water permeability

To UNE-EN 1062-3:2008: <0.1 kg/m² x h-0.5.

w < 0.1="" kg/m²="" x="">.

Carbon dioxide permeability

To UNE-EN ISO 7783:2012: >50 m.

Diffusion-equivalent air layer thickness (Sd).

Adhesion

After thermal compatibility.

To UNE-EN 13687-1&2:2002: >1.5 MPa.

With de-icing salt immersion and thunder shower cycling.

Abrasion resistance

To UNE-EN ISO 5470-1:1999, weight loss <3000 mg.

Taber.

Slip resistance

To UNE-EN 13036-4:2003, Class III (>55 units wet test).

Impact resistance

To UNE-EN ISO 6272-1:2012, Class III (>20 Nm).

Chemical resistance

To UNE-EN 13529:2005, group 1, 3 & 10: No defects & reduction in Shore Hardness <50%.

Resistance to chloride ions, to DOT BD47/94: Appendix B, Method B4,2(d): No chloride ion penetration after 28 days.

Shrinkage

To UNE-EN 12617-1:2004 (linear): <0.3%.

Reaction to fire

To EN 13501-1, Cfl-s1.

Cure time

Walk on: 1 hour, full traffic and chemical cure: 2–3 hours.

Typical properties achieved in laboratory tests at 20°C and at 50% Relative Humidity for a model specification.
