Application

Suitable for refurbishment of existing car parks and on new construction projects.

IMPORTANT: All specification information must be checked against the individual site requirements. Flowcrete advises that specifications are confirmed with their technical experts.

Description

A flexible, solvent free polyurethane car park deck coating system which cosmetically enhances and reduces noise. Suitable for exposed car park decks.


Features and benefits:

  • Chemical resistant.
  • Slip resistant.
  • Solvent free.
  • Aesthetically attractive (six colours).
  • Environmental friendly.
  • Heavy duty.
  • Reduces noise.

General information

Color

Blue

Green

Grey

Purple

Red

Finish

Gloss

Material

Polyurethane

Warranty description

Ten year

Uniclass

Ss_30_42_54_75 Resin flooring systemsPrimary

CAWS

M12/10 Resin flooring

M12/110 Resin flooring

Specification data - Resin flooring systems

Substrate

-

Testing

Insert requirements or omit.

-

Preparation

Concrete or screed substrate should be a minimum of 25 N/mm², free from laitance, dust and other contamination and should be dry to 95% RH as per BS 8203.

Primer

Deckshield EP.

For new builds.

Deckshield SF.

For refurbishment.

Resin flooring

Flexible polyurethane coating.

Surface treatment

Not required.

Deckshield UV topcoat.

Resin skirtings and upstands

Insert requirements or omit.

-

Adhesion

>1.5 N/mm².

Certification

CE Marked.

Chemical resistance

Protects against diesel, antifreeze, hydraulic fluids, chlorides and battery acids.

Chloride ion resistance

No penetration after 28 days.

DOT BD47/94: Appendix B, Method B4,2(d).

Colour options

Dark Grey.

Forest Green.

Mid Grey.

Tile Red.

Traffic Blue.

Show more

Crack bridging

To UNE-EN 1062-7:2004, Class A3 at -10°C; no cracks at -20°C.

Cure time

Light traffic: 16 hours, Full traffic: one day, full chemical cure: seven days.

At 20°C. See manufacturer's literature for other temperatures.

Impact resistance

Class II: ≥10 Nm.

Retroflectivity

Not required.

Required.

By request. Consult manufacturer for details.

Slip resistance

To UNE-EN 13036-4:2003, Class III: > 55 units wet.

Temperature resistance

Softens over 70°C and hardens on cooling.
