ALU-1237 Solid Aluminium Security Roller Shutter - Roller Shutter

Verified by manufacturer 4 months ago

ALU-1237 Manual

UK Roller Shutters Ltd Variant:

This shutter offers strong security with an extruded profile. Upgradeable to LPS1175 SR1, it comes in white or brown, & can be powder coated in any RAL/BS colour. Options include perforated or punched

Jump to:
+44 (0)1384 221743 Website

Application

Suited to windows and doors to domestic or commercial properties where looks are important, including:

  • Office doors and windows.
  • Bars.
  • Reception counters.
  • Display areas.
  • Shop fronts.
  • Domestic properties.
  • Garage doors.
  • Van and vehicle shutters.

Description

Aluminium roller shutter that combines strength with aesthetics. Made from 37 mm extruded aluminium, the shutter can be upgraded to LPS1175 SR1 if required. The product can also be punched or perforated to allow for vision/ airflow if required. The shutters can be programmed to run from a variety of control methods.


If insulation and sound reduction are more important, the ALU-12M37 model may be more appropriate.


Features and benefits:

  • Large range of Aluminium shutters that offer a secure and weatherproof solution to safeguarding large or small openings.
  • Traditionally gives a better cosmetic appearance to that of a steel shutter.
  • Much lighter than a steel shutter so less energy is required to open them.
  • Powder coated white or brown as standard. Can be powder coated to any standard RAL/BS colour for an additional charge.
  • Options for vision and airflow using punched or perforated lath.
  • Fully CE marked.
  • Protection against crushing, shearing or drawing in.

General information

Color

Brown

White

Finish

Powder-coated

Material

Aluminium

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

One year

Guidance for specification option:

On electrical parts.

Uniclass

Pr_30_59_84_73 Roller shuttersPrimary

CAWS

L20/60 Doors

L20/610 Roller shutters/ curtains

Specification data - Roller shutters

Opening sizes

-

Manufacturer guidance

Bespoke, available on request.

Arrangement

Vertical.

Performance

-

Resistance to wind load

Class 2.

Shutter curtain

-

Lath material

Aluminium.

Profile

Solid.

Perforated.

Punched.

Punched with polycarbonate inserts.

Guidance for specification option:

Additional cost if required.

Finish and colour

Polyester powder coated, brown.

Polyester powder coated, white.

Polyester powder coated, RAL/BS colour.

Guidance for specification option:

Additional cost.

Frame and guides

-

Material

Aluminium.

Finish

Powder coating.

Colour

Brown.

Guidance for specification option:

RAL 8019.

White.

Guidance for specification option:

RAL 9016.

RAL/BS colour.

Guidance for specification option:

Can be powder coated or plastisol coated to any stock RAL/BS colour for an additional cost.

Operation

-

Mode

Manual.

Control

Cord belt.

Guidance for specification option:

For smaller shutters.

Spring and lock.

Guidance for specification option:

For smaller shutters.

Rod and crank.

Blind

37.5 mm.

Manufacturer guidance

Curtain slat blind surface.

Weight

7.3 kg/m².

Manufacturer guidance

Curtain slat weight per m².

Width

4000 mm.

Manufacturer guidance

Curtain slat maximum width.

Surface

9 m².

Manufacturer guidance

Curtain slat maximum surface.

U-value

N/A Unrated.

Dimensions

1050 x 150 mm.

1535 x 165 mm.

Guidance for specification option:

Circular box available for an additional cost.

1820 x 180 mm.

2795 x 205 mm.

Guidance for specification option:

Circular box available for an additional cost.

3550 x 250 mm.

Show more

Manufacturer guidance

Guide height x plate size.

Plate sizes shown as a guide only and may vary.

Guide channels depth

45 mm.

53 mm.

60 mm.

66 mm.

Material

Extruded aluminium with brush inserts.

Manufacturer guidance

Guide channels.

Bottom slat

Extruded aluminium with weather seal.

Manufacturer guidance

Bottom slat material.

Enclosure material

Roll-formed aluminium with pressure-moulded aluminium end plates.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Aluminium

Manufacturing plant location

Recyclability

Mostly recyclable as 95% of the product is aluminium

Expected Life

30 year

Literature

ALU-1237 Brochure

ALU-1237 Brochure

ALU-1237-Drawings_datasheet

ALU-1237-Drawings_datasheet
