AGS 300 Narrowline

Verified by manufacturer 5 months ago

Capral Aluminium Third party certifications:
  • Declare

    Declare

    Certificate type

The AGS 300 Narrowline’s slimline frame depth and ability to accommodate a captive glazing wedge makes it an economical option.

Jump to:
+61 7 3816 7500 Website

Application

Residential or commercial aluminium framed glazing and internal glazing.

Description

The AGS 300 Narrowline aluminium framing system is designed to provide a crisp, narrow Commercial appearance with unbroken lines and face- matched mullion, transom and frame profiles. The centre glazed configuration can also incorporate adaptors to accommodate hinged doors and operable windows. Its slimline frame depth and ability to accommodate a captive glazing wedge makes it an economical option for shop front applications of modest dimensions or alternatively for use in internal partitioning applications.

General information

Material

Aluminium

Shape

Rectangle

Manufacturer guidance

Various profiles available.

Width

2000 mm

Height

3300 mm

Warranty description

Six year

Uniclass

Pr_30_59_99_02 Aluminium window wallsPrimary

NATSPEC National Classification System

0451a Windows and Glazed Doors – Metal

0451 Windows and Glazed Doors

SpeedSpec

08520 Metal Windows and Glazed Doors

SpecPack

08520 Metal Windows and Glazed Doors

Specification data - Aluminium window walls

Standard

To AS 2047

Dimensions and configurations

Various dimensions and configurations - see product literature

Frame dimensions

76mm x 35mm.

Manufacturer guidance

 For detailed mullion information please contact Capral Spec Team. This system is limited to a height of 3.3m and Mullion Spacing of 2.0 m.



Glazing

Single.

Performance:

Max SLS: 2200pa / ULS: 4300pa / WATER: 600pa.

Standard

AS2047.

Cyclonic impact testing

No

Bushfire attack level (BAL)

up to BAL29 DTS.

Sustainability data

Contains Red List materials

No

Country of material origin

Australia

Country of product manufacture

Australia

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

8 kg·CO₂e/kg

Self declared

Recyclability

100% recyclable.

Third party certifications

Declare

Declare

Aluminium Framing Systems Capral Fabricator Network

Literature

AGS 300 Narrowline Technical data manual 2207

AGS 300 Narrowline Technical data manual 2207

Extrusion wall chart AGS Narrowline 2207

Extrusion wall chart AGS Narrowline 2207

Extrusion Wall chart AGS subframing 2207

Extrusion Wall chart AGS subframing 2207

AGS Sub Framing Tech Manual 2207

AGS Sub Framing Tech Manual 2207
