AGS 1029 Flushline double glazed (250mm)

Verified by manufacturer 5 months ago

Capral Aluminium Third party certifications:
  • Declare

    Declare

    Certificate type

The AGS 1029 Commercial Flushline framing system has been developed to accommodate both internal and external glazing techniques.

Jump to:
+61 7 3816 7500 Website

Application

Residential or commercial aluminium framed glazing.

Description

The AGS 1029 Commercial Flushline framing system has been developed to accommodate both internal and external glazing techniques. Its front glazed arrangement has been designed to maximise internal areas whilst achieving a clean and modern external appearance. A uniform external appearance also allows various frame widths to be used whilst maintaining a consistent look. In addition to these features, the AGS 1029 Flushline system is available in single or double glazed form, incorporates optional structurally glazed mullion profiles and offers a number of operable door and window options.

General information

Finish

Powder-coated

Material

Aluminium

Shape

Rectangle

Width

2400 mm

Height

6000 mm

Warranty description

Six year

Uniclass

Pr_30_59_99_02 Aluminium window wallsPrimary

NATSPEC National Classification System

0451a Windows and Glazed Doors – Metal

0451 Windows and Glazed Doors

SpeedSpec

08520 Metal Windows and Glazed Doors

SpecPack

08520 Metal Windows and Glazed Doors

Specification data - Aluminium window walls

Standard

To AS 2047.

Dimensions and configurations

Various dimensions and configurations - see product literature

Product performance

-

Serviceability limit state (SLS)

4,500 Pa.

Ultimate limit state (ULS)

10,500 Pa.

Whole window U-value

-

Manufacturer guidance

U value dependant on overall size and configuration.

Integral accessories

Silicon joint external face.

Frame dimensions

250 x 55 mm.

Manufacturer guidance

 For detailed mullion information please contact Capral Spec Team. This system is limited to a height of 6.0m and a Mullion Spacing 2.4m.

Glazing

Single.

Double.

Performance:

Max SLS 4,500 Pa.

ULS 10,500 Pa.

Water 900 Pa.

Acoustics

Rw 39(-1; -4).

Cyclonic impact testing

No

Bushfire attack level (BAL)

BAL 40

Sustainability data

Country of material origin

Australia

Country of product manufacture

Australia

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

8 kg·CO₂e/kg

Self declared

Recyclability

100% Recyclable.

Third party certifications

Declare

Declare

Aluminium Framing Systems Capral Fabricator Network

Literature

AGS Sub Framing Tech Manual 2207

AGS Sub Framing Tech Manual 2207

Extrusion Wall Chart AGS Flushline 100 & 250mm 2208

Extrusion Wall Chart AGS Flushline 100 & 250mm 2208

Extrusion Wall chart AGS subframing 2207

Extrusion Wall chart AGS subframing 2207

AGS 1029 Flushline Technical Data Manual 2208

AGS 1029 Flushline Technical Data Manual 2208
