NBS Source

Application

Can be integrated with stainless steel worktops.

Description

Single stainless steel sink bowl.


Features and benefits:

  • For incorporating into a stainless steel worktop.
  • Available with a 20 mm flat flange for under-mount, over-mount or flush-mount fixing.
  • Custom sizes available.

General information

Color

Silver

Grey

Finish

Satin

Brushed

Material

Stainless steel

Steel

Shape

Rectangle

Length

440 mm

Width

440 mm

Height

200 mm

WarrantyDescription

Five year

Uniclass

Pr_40_20_96_81 SinksPrimary

CAWS

N13/331 Sinks

N13/25 Sinks

Product range

Made to Measure / Bowls

Specification data - Sinks

Standard

To BS EN 274-1, BS EN 274-2 and BS EN 274-3.

Form

Inset.

Under-mounted.

Flush fit.

Bowls

One.

Drainers

None.

Materials

-

Body

Stainless steel type 1.4301 (304) to BS EN 10088-1.

Finish and colour

Brushed satin.

Size

440 x 440 x 200 mm.

L x W x H.

Water supply, overflow and waste holes

-

Water supply

No tap holes.

Overflow

Chainstay hole.

Waste

Centre.

89 mm basket strainer waste.

Flange

Not required.

20 mm flat flange.

Environmental information

Contains Red List materials

No

Recyclability

100

Recycled content

0 %

Digital objects

Platform Compatible Version Certified to
Revit

Revit 2017

1

2.0
IFC
-

1

2.0
Download now from NBS National BIM Library
