An inverted EPDM warm roof system.
For roofs with regular traffic, or roofs in severe weather climates.
The Inverted System is a variation of the conventional ballasted system. It is particularly suitable for roofs with regular traffic, or roofs in severe weather climates. It can be applied on any building that can accommodate the extra load of the ballast and where the roof slope does not exceed 10%.
Features and benefits:
System components:
Color | Black |
Material | Rubber |
Uniclass | |
CAWS | J42/12 Inverted roof covering J42/120 Inverted roof covering |
Insulation | - |
Type | Extruded polystyrene (XPS) boards.Insert thickness requirements. |
Attachment | Loose laid over the RubberGard EPDM membrane. |
Waterproof covering | - |
Type100% cured non-reinforced, Ethylene-Propylene-Diene Terpolymer (EPDM) synthetic rubber, manufactured in an ISO 9001 and ISO 14001 registered facility. Minimum unspliced width of 3.05 m. Specification compliance: UL Classified/ FM Approved. ASTM D 4637/ EN 13956 (CE Mark). 7500 hrs of Artificial Ageing as per EN 1297. | RubberGard™ EPDM LSFR Roofing Membrane 1.1 mm.RubberGard™ EPDM LSFR Roofing Membrane 1.5 mm. |
Attachment | Loose laid.Over rough substrates install a geotextile protection mat, 200 g/m² (minimum) weight, prior to laying the RubberGard EPDM membrane. |
Joints | Lap splices: 100 mm minimum overlap with 76 mm QuickSeam Splice Tape. |
Upper protection layer | Water flow reducing layer (WFRL).As recommended by the insulation supplier. It will be placed on the insulation layer prior to installation of ballast or slabs on supports. |
Surface protection | Geotextile protection mat, 200 g/m² (minimum) weight, and ballast layer, 50 kg/m² (minimum) weight. |
System accessories | QuickSeam Splice Tape.QuickSeam FormFlash.QuickSeam Flashing.QuickSeam SA Flashing.QuickSeam Reinforced Perimeter Fastening Strip.QuickSeam Universal Pipe Flashing.QuickSeam Conduit Flashing.QuickSeam Penetration Pocket.QuickSeam Walkway Pad.QuickPrime Plus.Lap Sealant HS.All Purpose (AP) Fasteners.Heavy Duty (HD) Fasteners.Splice Wash (SW-100).Cleaner C-20.Water-Block Seal (S-20).Pourable Sealer S-10 (Parts A & B).Coiled Metal Batten Strip.Metal Batten Strip.Termination Bar. |
Corners | QuickSeam FormFlash (external corners) and folded internal corners. |
Pipes | Pipe penetrations: QuickSeam FormFlash. Pipe penetrations: QuickSeam Pipe boots and Conduit Flashing. |
Outlets | Drains: Install Water Block Sealant between membrane and outlet bowl. Secure membrane mechanically to outlet using integral clamping ring. Drains: Insert outlet bedded on Water Block Sealant. Secure and flash with QuickSeam FormFlash or SA Flashing. |
Walls | Wall terminations: Termination bar, fastened with Water Block Sealant and Lap Sealant HS installed along top edge. @200mm (maximum) o.c. Wall terminations: Metal batten bar, fastened with surface mounted or inserted metal counter flashing protection. @150mm (maximum) o.c. Wall terminations: Metal capping or concrete coping stones. Wall termination: Preformed metal edge trim. |
