Enhanced Security Doorsets - Security Door

Verified by manufacturer 1 month ago

General

Principal Doorsets Ltd Variant:
Third party certifications:
  • BM Trada

    BM Trada

    Certificate type

A range of specialist doorsets designed exclusively to provide enhanced security against intrusion and attack.Tested to PAS 24: 2016

Jump to:
+44 (0)1237 439152 Website

Application

Specialist doorsets where enhanced security against intrusion and attack is a requirement. Internal or external use.

Description

Specialist doorsets designed exclusively to provide enhanced security against intrusion and attack.


Features and benefits:

  • Meets PAS 24 requirements for enhanced security.
  • Certification by accredited third-party certification body.
  • Manufactured using responsibly sourced materials.
  • Independently tested to the recognised PAS 24:2016 standards.
  • Supplied as a doorset with secure ironmongery and frames.
  • Frame finishes can be supplied to match the door.
  • Full customisation of all doors and finishes (subject to certification).
  • Principal Doorsets are members of the Exova/ BM Trada Q Mark Scheme.
  • Fire rating - FD30S (44 mm) and FD60S (54 mm).
  • Primed, veneered, laminated, stained or factory primed.
  • Range of ironmongery options.
  • FSC certified.


General information

Color

Other

Guidance for specification option:

Custom colour selection.

Finish

Other

Guidance for specification option:

Laminated


Painted


Primed


Stained


Veneered

Manufacturer guidance

Various Facing options available

Material

Wood

Medium density fibreboard (MDF)

Particleboard

Manufacturer guidance

Primary door leaf construction/ facing and frame materials only.

Shape

Rectangle

Length

Bespoke

Guidance for specification option:

Single Doorset - Door leaf Size

Between 950mm wide x 2400mm high

Double Doorset - Door leaf Size

Between 1050mm wide x 2400mm high


Width

Bespoke

Guidance for specification option:

Single Doorset - Door leaf Size


Between 950mm wide x 2400mm high


Double Doorset - Door leaf Size


Between 1050mm wide x 2400mm high

Height

Bespoke

Guidance for specification option:

Single Doorset - Door leaf Size


Between 950mm wide x 2400mm high


Double Doorset - Door leaf Size


Between 1050mm wide x 2400mm high

Warranty description

One year

Uniclass

Pr_30_59_24_97 Wood doorsetsPrimary

CAWS

L20/410 Wood doorsets

L20/55 Doorsets

Specification data - Wood doorsets

Standard

Fire-rated doorset third-party-certified to PAS 24:2016.

Wood in joinery standard

To BS EN 942.

Configuration

Single-leaf, single-action - inward opening.

Single door - inward and outward opening.

Double door - inward and outward opening.

Double-leaf, single-action.

Leaf and part-leaf, single-action.

Single-leaf, single-action.

Double-leaf, single action.

Double-leaf, single action with solid overpanel.

Single leaf single action with solid overhead panels.

Single leaf single action with solid side panels.

Doorset size

Guidance for specification option:

Insert requirements, maximum (w x h, not including frame): 1100 x 2400 mm.

Performance

-

Fire resistance

-

Integrity

To BS EN 13501-2, E 30 minutes.

To BS EN 13501-2, E 60 minutes.

Not applicable.

Insulation

To BS EN 13501-2, I 30 minutes.

To BS EN 13501-2, I 60 minutes.

Not applicable.

Acoustic performance

To BS EN ISO 10140-2, sound reduction index Rw 37 dB minimum.

Strength and durability

To BS EN 1192, Class 4.

Thermal

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Intruder resistance

-

Minimum requirement

To PAS 24.

Application

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Conformity

Certification by accredited third-party certification body (BM TRADA).

Frame

-

Material

Hardwood.

Species

Maple.

Ash.

Koto.

Beech.

American white oak.

American black walnut.

Sapele.

Appearance class

J10.

Threshold

Exitex MDS 25.

MDS 80/2.

MDS150/2.

Sealed Tight Solutions STH004.

Exitex MXS/FS15.

Hardwood.

Perimeter seals or inserts

Acoustic seal.

Fire and smoke seal.

Manufacturer guidance

Consult manufacturer for details.

Finish

To match door leaf.

Other.

Guidance for specification option:

Insert requirements.

Colour

To match door leaf.

Other.

Guidance for specification option:

Insert requirements.

External

To match door leaf.

Other.

Guidance for specification option:

Insert requirements.

Internal

To match door leaf.

Other.

Guidance for specification option:

Insert requirements.

Installation fasteners

Screws.

Guidance for specification option:

Insert requirements to suit substrate.

Frame accessories

European redwood stops, 44 x 15 mm.

Door leaf

-

Thickness

44 mm.

Guidance for specification option:

Construction:

  • Stiles and rails: None.


Consult manufacturer for full details. See below for core, facings etc,

54 mm.

Core

Solid core.

Guidance for specification option:

Consult manufacturer for details.

Panel details

Solid.

Guidance for specification option:

Side panels and overpanels (where appropriate).

Facings

Manufacturer's standard.

Species

Hardwood.

Cut

Crown cut veneer.

Quarter cut veneer.

Rift cut veneer.

Lippings

Concealed lippings to long edges.

Guidance for specification option:

8 mm thick; density: 640 kg/m³.

Adhesive: Polyurethane.

Exposed lippings to long edges.

Hardwood to match facing veneers.

Perimeter seals

Lorient Drop Down Seal ref. LAS8001-1135.

Finish

Guidance for specification option:

Consult manufacturer for details and insert requirements.

Colour

-

External

Guidance for specification option:

Consult manufacturer for details and insert requirements.

Internal

As External.

Other.

Guidance for specification option:

Insert requirements.

Glazing

-

Type

Not required.

26 mm-thick double-glazed insulating glass unit (IGU).

42 mm-thick triple-glazed insulating glass unit (IGU).

Manufacturer guidance

Standard glazing details:

  • Overall size (w x h): 300 x 1000 mm.
  • Sight size (w x h): 274 x 970 mm.
  • Internal & external cassettes, around internal and external perimeter of glazing: Maple 24 x 14 mm (minimum).
  • Cassette fixings: 16 No. 60 x 2 pins.
  • Sealant: Dow Corning 785 Silicone.


All insulating glass units used within a Q-Mark certified door must:

  • Have accredited certification to EN 1279 parts 2 & 6 or accredited  certification to ISO 9001 with accredited EN 1279-2 ITT & audit testing (MPI +  fogging) or CE Marked to AVCP 1 with accredited EN 1279-2 ITT & audit  testing (MPI + fogging). N/A to Fire Doors which must be CE Marked to AVCP 1.
  • Have at least 1 pane of glass laminated to BS EN 356 class P1A or higher.

Manifestation

Guidance for specification option:

Insert requirements or omit.

Hardware

Hardware option 1.

Guidance for specification option:

  • Hinges: 4 No. Eurospec ref. HIN1433SEC/13;
  • Locking mechanism: Winkhaus STV-F Cobra ref. 2069 M3;
  • Keeps: Upper: 2 No. Winkhaus ref. 2938393; lower: 1 No. Winkhaus ref. 2938393; centre: Winkhaus ref. 4929149/152;
  • Door closer (internal): Britton Allegion concealed closer ref. 2420 TPS.
  • Letter plate: Royde & Tucker LP0/C with cowl.

Hardware option 2.

Guidance for specification option:

  • Hinges: Halspan H30 Steel Hinges ref. HIN-BSS-103/4;
  • Locking mechanism: Winkhaus AV2 ref. F2070/45 92/8;
  • Keeps: Upper/lower: Winkhaus .AV2 (Ref. F24-908WR/END MV1 FX4; centre: Winkhaus ref. F24-908WR U RS;
  • Door closer (internal): Britton Allegion concealed closer ref. 2420 TPS.
  • Letter plate: Royde & Tucker LP0/C with cowl.

Hardware option 3.

Guidance for specification option:

  • Hinges: Cooke Brothers butt hinge, stainless steel. ref.7730;
  • Locking mechanism: Winkhaus AV2 ref. F2070/45 92/8;
  • Keeps: Upper/lower: Winkhaus .AV2 (Ref. F24-908WR/END MV1 FX4; centre: Winkhaus ref. F24-908WR U RS;
  • Door closer (internal): Britton Allegion concealed closer ref. 2420 TPS.
  • Letter plate: Royde & Tucker LP0/C with cowl.

Manufacturer guidance

Manufacturer's standard hardware list: Handle and cylinder specified separately (see below).


Alternative cylinder/ handle combination and/or letterplate can be used subject to requirements of PAS 24:2016. Consult manufacturer for details.

Rebate size

Not applicable.

Performance

Weather rating, to BS 6375 Part 1 Exposure category 800X (on largest specimen).

Handles

Mila 115 mm lever handles ref. 050202.

Winkhaus Palladio 110 mm quick fit lever handles, 44 mm.

Cylinders

Eurospec MPX6 70 mm cylinder ref. T5007.

Winkhaus 70 mm cylinder ref. XR651.

Manufacturer guidance

Thumb-turn option: Yes.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

0.25 kg CO₂ eq/kg

Self declared

Manufacturer guidance

Carbon content varies between core types.


For further detail please contact manufacturer.

Recyclability

>80%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

-

Manufacturer guidance

Recycled content varies between core types.

For further detail please contact manufacturer.

Third party certifications

BM Trada

BM Trada

Q-Mark Enhanced Security Door PAS 24:2016 and BS 644:2012 Timber

BM Trada

BM Trada

Q-Mark Fire Door Manufacture STD006
