CLAD-LINE CL4 Framing System - Framing System

Name: CLAD-LINE CL4 Framing System - Framing System
Brand: Clad-Line Framing Solutions
SKU: sy82h7aXFgUYWEmCPToYyn

Verified by manufacturer over a year ago

Clad-Line Framing Solutions

Rainscreen framing system. For panel systems using face fixings or discrete mechanical fixings.

Jump to:

+44 (0)1543 222 500 Website

Application

For panel systems using face fixings or discrete mechanical fixings.

Description

CL4 is CLAD-LINE’s non-combustible alternative to timber battens, comprising of Top-Hat and Zed profiles which can be fixed directly back to the main structure. The CL4 system has been designed with oversized flanges to make fixing easier. Suitable for rainscreens with a shallow cladding zone (25 or 40 mm), this system can be used with a wide range of face fixed cladding panels.

Features and benefits:

Lightweight.
Durable.
Cavity range from 25 to 40 mm .
Suitable for use with Rockpanel, aluminium, HPL, ACM and fibre cement.
Non-combustible.
Suitable for new build and refurbishment.
Faced fixed panel installation.
Cost effective installation.
100% recyclable aluminium.
Powder coated or anodized finishes available on request.

General information

Color	Silver
Finish	Mill Powder-coated Guidance for specification option: Available on request. Anodized Guidance for specification option: Available on request.
Material	Aluminium
Shape	Rectangle
Length	3000 mm 6000 mm
Width	Bespoke
Height	Bespoke

Uniclass	Pr_20_85_20_04 Aluminium carrier railsPrimary
CAWS	H92/120 Rainscreen cladding

Specification data - Aluminium carrier rails

Rails	Top Hat (120 x 25) 45 x 25 x 35 3000 mm CL4-TH/120X25/3000. Top Hat (120 x 25) 45 x 25 x 35 6000 mm CL4-TH/120X25/6000. Top Hat (140 x 40) 55 x 40 x 35 3000 mm CL4-TH/140X40/3000. Top Hat (140 x 40) 55 x 40 x 35 6000 mm CL4-TH/140X40/6000. Zed 45 x 25 x 32 3000 mm CL4-ZED/45X25/3000. Zed 45 x 25 x 32 6000 mm CL4-ZED/45X25/6000. Zed 55 x 40 x 32 3000 mm CL4-ZED/55X40/3000. Zed 55 x 40 x 32 6000 mm CL4-ZED/55X40/6000. Show more
Fixings	- Manufacturer guidance Insert requirements. A range of fixings are available. All fixings can be colour matched.
Accessories	Double A2 Isolator Pad [CL-DOUBLEPAD/A2]. Single A2 Isolator Pad [CL-SINGLEPAD/A2].

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Recyclability	Fully recyclable
Recycled content As defined in clause 7.8 of BS EN ISO 14021	65 %
