Walls
Walls includes various wall structure and cladding systems such as unit walls structures, framing, cladding and linings. Browse products for Walls below.
Can't find what you're looking for?
Recently verified
Showing 1-36 of 2008
HD1057 Hush Wall System On Existing Masonry - Acoustic Wall System
Verified 13 hours ago
Hush Acoustics
Acoustic wall system designed to line existing block or masonry walls.
GypLyner Independent - B216005 (B) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc SoundBloc 12.5mm to one side of Gypframe 60 I 50 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 3000mm.
GypLyner Independent - B216004 (F) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc WallBoard 15mm to one side of Gypframe 146 I 80 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 4000mm.
GypLyner Independent - GIWL 92 I 90 PIR (A) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc ThermaLine PIR 38mm to one side of Gypframe 92 I 90 ‘I’ Stud framework forming an independent lining to masonry background. For heights up to 4200mm.
GypLyner Independent - B216028 (B) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc FireLine 15mm to one side of Gypframe 60 I 50 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 3300mm.
GypLyner Single - B226010 (EN)
Verified 21 hours ago
British Gypsum
103mm solid brick wall of density 1700 kg/m³ with 13mm plaster each side and Gypframe GL1 Lining Channel framework fixed to both sides to give 35mm cavities with 25mm Isover Acoustic Partition Roll (APR 1200) in the cavities clad with one layer of Gyproc SoundBloc 12.5mm.
GypLyner Independent - B216005 (D) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc SoundBloc 12.5mm to one side of Gypframe 70 I 70 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 4000mm.
DriLyner Dab - TL-PIR (E) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc ThermaLine PIR 93mm on Gyproc DriWall Adhesive dabs (10mm nominal cavity) on solid masonry background
GypLyner Single - B226005 (EN)
Verified 21 hours ago
British Gypsum
100mm solid block wall of density 1700 kg/m³ with 13mm plaster each side and Gypframe GL1 Lining Channel framework fixed to one side to give 85mm cavity with 50mm Isover Acoustic Partition Roll (APR 1200) in the cavity clad with two layers of Gyproc SoundBloc 12.5mm.
GypLyner Independent - B216006 (C) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc SoundBloc 15mm to one side of Gypframe 60 I 70 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 3900mm.
DriLyner Dab - TL-PLUS (D) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc ThermaLine Plus 48mm on Gyproc DriWall Adhesive dabs (10mm nominal cavity) on solid masonry background
GypLyner Xternal - T106037 MR1 (EN)
Verified 21 hours ago
British Gypsum
A non-loadbearing external wall construction including a 20mm deflection head with one layer of Glasroc X Sheathing Board 12.5mm to external side and an inner layer of Gyproc SoundBloc 15mm with an outer layer of Gyproc SoundBloc MR 15mm to the internal side of 100mm Intrastack SFS framework. 50mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 4000mm.
GypLyner Independent - B216004 (B) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc WallBoard 15mm to one side of Gypframe 60 I 50 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 3300mm.
GypLyner Xternal - T106038 MR1 (EN)
Verified 21 hours ago
British Gypsum
A non-loadbearing external wall construction including a 20mm deflection head with one layer of Glasroc X Sheathing Board 12.5mm to external side and two inner layers of Gyproc FireLine 15mm and an outer layer of Gyproc FireLine MR 15mm to the internal side of 100mm Intrastack SFS framework. 50mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 4000mm.
GypLyner Single - TL-Universal (B) (EN)
Verified 21 hours ago
British Gypsum
Solid masonry background with Gypframe GL1 Lining Channel framework fixed to one side with a cavity between 25mm to 125mm clad with one layer of Gyproc ThermaLine PIR 53mm
GypLyner Independent - B216003 (B) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc WallBoard 12.5mm to one side of Gypframe 60 I 50 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 3000mm.
GypLyner Independent - GIWL 60 I 50 PIR (C) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc ThermaLine PIR 63mm to one side of Gypframe 60 I 50 ‘I’ Stud framework forming an independent lining to masonry background. For heights up to 2400mm.
GypLyner Xternal - T106039 (EN)
Verified 21 hours ago
British Gypsum
A non-loadbearing external wall construction, including a 20mm deflection head, with an inner layer of Glasroc X Sheathing Board 12.5mm and outer layer of 50mm Isover Polterm Max Plus insulation to external side and one layer of Gyproc FireLine 15mm to the internal side of 100mm Intrastack SFS framework. 50mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 4000mm.
DriLyner Dab - TL-PLUS (C) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc ThermaLine Plus 40mm on Gyproc DriWall Adhesive dabs (10mm nominal cavity) on solid masonry background
GypLyner Independent - GIWL 48 I 50 PIR (B) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc ThermaLine PIR 53mm to one side of Gypframe 48 I 50 ‘I’ Stud framework forming an independent lining to masonry background. For heights up to 2400mm.
GypLyner Independent - B216006 (D) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc SoundBloc 15mm to one side of Gypframe 70 I 70 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 4000mm.
DriLyner Fix - MF (C) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc WallBoard 15mm fixed to Gypframe MF10 Channel on Gyproc DriWall Adhesive dabs (20mm nominal cavity) on solid masonry background
GypLyner Single - B226008 (B) (EN)
Verified 21 hours ago
British Gypsum
100mm solid block wall of density 1700 kg/m³ with 13mm plaster each side and Gypframe GL1 Lining Channel framework fixed to one side to give 35mm cavity with 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity clad with one layer of Gyproc SoundBloc 12.5mm.
DriLyner Dab - BASIC (A) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc WallBoard 9.5mm on Gyproc DriWall Adhesive dabs (10mm nominal cavity) on solid masonry background
GypLyner Independent - B216026 (E) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc FireLine 15mm to one side of Gypframe 92 I 90 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 4000mm.
DriLyner Dab - BASIC (D) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc WallBoard Ten 12.5mm on Gyproc DriWall Adhesive dabs (10mm nominal cavity) on solid masonry background
GypLyner Independent - B216028 (D) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc FireLine 15mm to one side of Gypframe 70 I 70 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 4000mm.
GypLyner Independent - GIWL 60 I 50 PIR (B) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc ThermaLine PIR 53mm to one side of Gypframe 60 I 50 ‘I’ Stud framework forming an independent lining to masonry background. For heights up to 2400mm.
GypLyner Independent - GIWL 70 I 70 PIR (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc ThermaLine PIR 38mm to one side of Gypframe 70 I 70 ‘I’ Stud framework forming an independent lining to masonry background. For heights up to 3600mm.
GypLyner Independent - B216004 (E) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc WallBoard 15mm to one side of Gypframe 92 I 90 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 4000mm.
DriLyner Dab - TL-BASIC (A) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc ThermaLine Basic 22mm on Gyproc DriWall Adhesive dabs (10mm nominal cavity) on solid masonry background
GypLyner Independent - B216027 (C) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc FireLine 12.5mm to one side of Gypframe 60 I 70 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 3600mm.
GypLyner Single - TL-Universal (D) (EN)
Verified 21 hours ago
British Gypsum
Solid masonry background with Gypframe GL1 Lining Channel framework fixed to one side with a cavity between 25mm to 125mm clad with one layer of Gyproc ThermaLine PIR 78mm
GypLyner Independent - B216027 (B) (EN)
Verified 21 hours ago
British Gypsum
Two layers of Gyproc FireLine 12.5mm to one side of Gypframe 60 I 50 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 3000mm.
GypLyner Independent - B216026 (F) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc FireLine 15mm to one side of Gypframe 146 I 80 ‘I’ Stud framework with 50mm Isover Steel Frame Infill Batts between studs forming an independent lining to structural steel columns, in association with external steel cladding (0.6mm). For heights up to 4000mm.
GypLyner Independent - GIWL 92 I 90 PIR (B) (EN)
Verified 21 hours ago
British Gypsum
One layer of Gyproc ThermaLine PIR 38mm to one side of Gypframe 92 I 90 ‘I’ Stud framework forming an independent lining to masonry background. For heights up to 5100mm.
Showing 1-36 of 2008
