Centre Pivot Smoke Ventilation AOV Roof Window (FSR P2) - Smoke Vent Window
Verified by manufacturer 2 months ago
Pivot window equipped with smoke ventilation system.
Application
Suitable for roof pitches from 15–90°.
Description
Pivot window equipped with smoke ventilation system.
Features and benefits:
- Pinewood, natural colour (FSR), white NCS S0502-Y polyurethane (FSR/U), or white acrylic (FSR/W).
- Special actuator opening the sash up to an angle of 90°.
- Double sealing system.
- Universal installation system.
- Steel spacer.
General information
Color | White Other Grey |
Finish | Acrylic |
Material | Wood Timber Pine Glass |
Shape | Rectangle |
Warranty description | Ten year Guidance for specification option: For windows. 20 year Guidance for specification option: For glazing. |
Uniclass | |
CAWS | L10/46 Roof windows L10/47 Roof ventilators L10/490 Roof ventilators L10/480 Roof windows |
Specification data - Wood frame roof window units
Standard | To EN 12101-2:2003.Guidance for specification option: (Number of declaration of performance: R40/CPR/12101/17.) Manufacturer guidanceHarmonized standard: |
Product performance | |
Fire resistance | F. |
Frame | |
Finish as delivered | Pinewood, natural colour (FSR).White NCS S0502-Y polyurethane (FSR/U).White acrylic (FSR/W).RAL.Guidance for specification option: Wooden profiles can be painted in any RAL colour or in one of five azure colours. Insert colour code or reference; consult manufacturer for more details. |
Ventilator | Smoke ventilation system. |
Glazing or infill | |
Composition | Guidance for specification option: Consult manufacturer and insert requirements. |
Operation | |
Type | Manual.Electrically operated by control panel. |
Fixing features | Standard.Insulation sets.Guidance for specification option: Consult manufacturer and insert requirements. Linings.Guidance for specification option: Consult manufacturer and insert requirements. Auxiliary rafters.Guidance for specification option: Consult manufacturer and insert requirements. Bands.Guidance for specification option: Consult manufacturer and insert requirements. Frame extensions.Guidance for specification option: Consult manufacturer and insert requirements. |
Window size code | 23. Guidance for specification option: 777 x 781 mm. 05. Guidance for specification option: 777 x 981 mm. 06. Guidance for specification option: 777 x 1181 mm. 07. Guidance for specification option: 777 x 1401 mm. 24. Guidance for specification option: 937 x 781 mm. |
Flashings | Standard. Special. Guidance for specification option: Consult manufacturer and insert requirements. Combination. Guidance for specification option: Consult manufacturer and insert requirements. |
Mullion | Not required. Required. |
External cladding finish | Not required. Required. Guidance for specification option: External cladding elements painted in any RAL colour or manufactured to match even the most electrically operated by control panel (not included in set) unusual roofing colours (CU, TC). Insert colour code or additional requirements; consult manufacturer for more details. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Poland |
Country of product manufacture | Poland |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 61.3 kg CO₂ eq/kg Self declared |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 53 % |
Literature
FSR Data Sheet
