CellPave™ 40 - Interlocking Cellular Paving Grid System

Name: CellPave™ 40 - Interlocking Cellular Paving Grid System
Brand: Green-Tech
SKU: eE1ZPHgQ4DEtLqQ65Wjb7H

Verified by manufacturer 2 days ago

CellPave 40 grass and gravel pavers are an interlocking cellular paving grid system for grass and ground reinforcement applications where there is regular pedestrian or vehicle use.

Jump to:

Request BIM

+44 (0)1423 332114 Website

Application

For grass and ground reinforcement applications where there is regular pedestrian or vehicle use.

Designed for applications such as:

Grass and gravel car parks;
Overflow car parks;
Aircraft taxiways and helipads;
Pedestrian walkways;
Wheelchair/ disabled access routes;
Golf buggy paths;
SUDS source control.

Description

CellPave 40 grass and gravel pavers are an interlocking cellular paving grid system for grass and ground reinforcement applications where there is regular pedestrian or vehicle use.

Features and benefits:

Open cell structure allowing unrestricted healthy grass root growth.
SuDS source control compliant.
Attractive paving solution with a natural grass or permeable retained gravel surface.
25 mm ground spikes resist lateral forces caused by vehicles.
Fast and easy to install.
Manufactured from 100% recycled plastics and are UV stabilized.
Plastic grass paving grids are chemically inert, non-toxic and rot-free.
Frost resistant and weather resistant.
An eco-friendly, sustainable paving solution for trafficked areas.

General information

Color	Black
Finish	Smooth
Material	High density polyethylene (HDPE)
Shape	Square
Length	500 mm
Width	500 mm
Height	40 mm Guidance for specification option: Excluding 25 mm ground spikes.

Uniclass	Pr_25_93_60_61 Plastics cellular paversPrimary
CAWS	Q25/62 Plastics pavers Q25/350 Plastics pavers

Specification data - Plastics cellular pavers

Classification data
Physical properties	-
Material	Recycled HDPE.
Colour	Black.
Profile	-
Paver type	Regular plan form, square.
Interlocking features	Included.
Dimensions	-
Plan size	500 x 500 mm.
Thickness (minimum)	40 mm. Guidance for specification option: Excluding 25 mm ground spikes (four per paver).
Load-carrying capacity (minimum)	305 tonne/m². Guidance for specification option: Tested by Lloyds British.
Environmental performance requirements	-
Environmental rating	Environmentally neutral, tested to ISO 1185/ ISO 17294-2A/ DIN EN 17933.
Recycled content (minimum)	100%.
Weight	1.2 kg per unit (4.8 kg/m²).
Cell Size	60 mm octagonal. Guidance for specification option: Cell wall thickness: 2.7–3.2 mm. Cell openness: 95% on top, 75% on base.
Accessories	White markers/ delineators. Guidance for specification option: Consult manufacturer and insert required numbers. Not required.
