Advantage Tennis Court Fencing

Verified by manufacturer 4 months ago

Advantage Tennis 6

Zaun Limited Variant:

Tennis court fencing system, designed specifically for use behind serving lines to increase ball retention.

Jump to:
+44 (0)1902 796699 Website

Application

  • Civic and public sector.
  • Schools and education.
  • Sport and leisure.

Description

'Advantage Tennis' tennis court fencing systems are designed to withstand heavy use whilst still maintaining easy viewing of the on court action. They use a 42.85 x 200 mm twin wire mesh, which results in an extremely durable tennis court perimeter and enhances the area in which it is situated. The 42.85 x 200 mm mesh also means that there is no chance of the tennis ball passing through the fence, increasing ball retention and gameplay. The twin horizontal wires also ensure that the court could be used for other high impact sports like football to increase the court usability. The Advantage Tennis systems use EPDM rubber inserts at every fixing to reduce noise and eliminates rattle during play, and a full length clamp bar covers the panel ends to ensure a safer playing surface with no sharp edges.


Traditionally, chain-link fencing is used for tennis courts, which is a classic example of how the lowest cost solution does not equal the best value. Easily cut with pliers, people gain access out of hours by snipping the fence, encouraging inappropriate use of the courts and making them an eyesore. The Advantage Tennis systems rigid design ensures that not only is it difficult for vandals and intruders to gain access, but unlike chain-link fencing they do not deform with continuous play or when people lean or push against it.


Features and benefits:

  • Specifically designed for tennis courts.
  • Tight mesh apertures eliminates tennis ball loss and increased ball retention.
  • Supplied with EPDM inserts and fixings to reduce noise caused by ball impacts.
  • Open mesh design gives provides better viewing for spectators.
  • No solid surface for graffiti.
  • Low maintenance with rigid mesh pattern that will not deform like chain-link fencing.
  • Difficult to cut for vandals.
  • Available either bolt down, in ground or on wall.
  • Mesh apertures are reduced to ensure that a tennis ball cannot pass through to increase ball retention.

General information

Color

Green

Black

Other

Manufacturer guidance

RAL 6005 or RAL 9005 as standard - but any RAL colour is available.

Finish

Galvanized

Powder-coated

Material

Steel

Width

2510 mm

Height

3030 mm

Uniclass

Ss_25_14_61_51 Metal mesh panel fencing systemsPrimary

CAWS

Q40/125 Open mesh steel panel general purpose fencing

Q40/27 Open mesh steel panel general purpose fencing

Q40/30 Proprietary fencing

Q40/430 Proprietary fencing

Specification data - Metal mesh panel fencing systems

Standard

To ISO 12944, BS 1722.

Posts

80 x 40 mm rectangular hollow section (RHS) sports posts.

Guidance for specification option:

Sizes dependent on height, spaced at 2525 mm centres, consult manufacturer.

Panels

Advantage Tennis 6 mesh.

Guidance for specification option:

Comprising 42.85 x 200 mm with dual 6 mm horizontal wires at 200 mm centres with single 5 mm vertical wires at 42.85 mm centres.

System accessories

Not required.

Pedestrian gates.

Guidance for specification option:

Single leaf, 1.2 m wide, or width to suit, consult manufacturer and insert requirements.

Vehicular gates.

Guidance for specification option:

Double leaf, 3.0 m wide, or width to suit, consult manufacturer and insert requirements.

Height

3030 mm.

Manufacturer guidance

Other heights are available upon request.

Applied finishes

Galvanized and polyester powder coated.

Colour

RAL 6005.

Guidance for specification option:

As standard.

RAL 9005.

Guidance for specification option:

As standard.

Other.

Guidance for specification option:

Available in any RAL colour, insert requirements.

Fixing

Bolt down.

In ground.

Wall.

Gates

50 x 50 mm RHS frame, Advantage Tennis mesh welded inside the frame, slide latch, rubber bump stop and two gate posts.

Panel fixings

Panels fixed to posts with full height 40 x 5 mm clamp bar with bolt fixings at 200 mm centres with EPDM inserts.

Guidance for specification option:

The full height clamp bars create a flush safe finish with the mesh ends behind the clamp bar.

WireDiameter

6 mm / 2 x 8 mm.

Guidance for specification option:

Vertical x Horizontal.

Width

2510 mm.

Fixings

Anti tamper security fixings.

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom
