Tradeline Wall Lining - Wall Lining System
Verified by manufacturer 7 days ago
Tradeline - T&G Edge
Tradeline - T&G Edge
Commercial wet-wall lining system.
Application
Suitable for use as a shower cladding solution for commercial and healthcare applications, as well as residential developments.
Description
Commercial wet-wall lining system, manufactured from moisture-resistant medium density fibreboard (MR MDF).
Features and benefits:
- Easy to clean due to antibacterial and mould-resistant non-porous surface.
- Provides a cost-effective alternative to traditional tiling.
- Options of square edge or tongue and groove format available.
- Supplied with complementary trims.
- Forms a completely waterproof system.
- Wide range of colour options.
General information
Color | Black Brown Grey White Beige |
Finish | Matt Textured Laminated Gloss Woodgrain |
Material | Medium density fibreboard (MDF) High pressure laminate (HPL) Aluminium |
Shape | Rectangle Other |
Width | 580 mm 1180 mm 1200 mm |
Height | 2420 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | K13/160 Proprietary K13/160 Proprietary K32/15 Duct/ wall lining panels K32/140 Duct/ wall linings – panels only |
Specification data - Duct and wall panel lining systems
Classification data | |
Panels | Moisture-resistant medium-density fibreboard (MR MDF), Rearo HPL-faced both sides, 9 mm. |
Non-integral finishes | One long edge tongued, and one long edge grooved. Both short edges are square and clean cut. |
Fasteners | Panel adhesive and mechanical fixing through the grooves/ extrusions of the panel. Guidance for specification option: As per manufacturers fitting instructions. |
Supporting frame | |
Duct panels | By others. |
Wall panels | By others. |
System accessories | Extrusions/ trims (satin anodized aluminium). Guidance for specification option: 2450 mm long extrusions SAA (satin anodized aluminium), black, white, or polished chrome. To suit a variety of bathroom shapes, Rearo stock a range of panel trims to assist in the cladding of an area. Select from internal and external corners, as well as end caps and H-sections. |
Dimensions | 2420 x 580 mm. 2420 x 1180 mm. Manufacturer guidanceStandard full-size panels cover approximately 2.88 m2 and half-size panels 1.4 m2. |
Finish | Manufacturer guidanceConsult manufacturer and insert requirements. |
Compensator Board | Rearo Balancer HPL, 11 mm. |
Core fire rating | Class 2. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Ireland |
Country of product manufacture | United Kingdom |
Manufacturing plant location | |
Material | Medium density fibreboard (MDF) High pressure laminate (HPL) Aluminium |
Recyclability | Tradeline panels can be recycled into other uses or used as bio-mass. Aluminium extrusions can be recycled repeatedly without losing it's quality. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 60 % |
Expected Life | Ten year |
