Stratobel Security
Verified by manufacturer 7 months ago
Anti-bandit, basic protection
Anti-bandit, basic protection
Anti-burglary, bulletproof and anti-explosion glass solutions.
Application
Projects requiring a high level of security. Can be easily installed in standard existing windows. Suitable for:
- Doors and partitions;
- Facades and curtain walls;
- Retail and museum display cases;
- Shopfronts;
- Windows.
Description
Anti-burglary, bulletproof and anti-explosion glass solutions.
Features and benefits:
- Available in three levels of security: Bullet (EN 1063), burglary (EN 356) and explosion (EN 13541).
- Neutral appearance.
- Thin and lightweight.
- Custom solutions: Security, aesthetics and other functions such as solar control, thermal insulation and acoustic insulation can be merge into a single product.
- Sustainable: Cradle to Cradle Certified™ Bronze.
- CE Marked. Test documents and certificates are available on request.
- Ten-year warranty.
For options providing protection from injuries and falls (to EN 12600), see the Stratobel product (specified separately).
General information
Color | Clear |
Material | Glass |
Warranty description | Ten year |
Uniclass | |
CAWS | H10/10 Patent glazing H10/115 Patent glazing H11/110 Curtain walling H13/115 Structural glass assembly L10/10 Wood windows L10/15 Wood windows L10/20 Steel windows L10/210 Wood windows L10/25 Aluminium windows L10/30 PVC-U windows L10/31 PVC-U windows L10/310 Steel windows L10/33 Proprietary windows L10/330 Aluminium windows L10/350 PVC-U windows L10/390 Proprietary windows L10/400 Composite windows L10/58 Secondary glazing system L10/580 Secondary glazing system L40/210 Putty-fronted single glazing L40/230 Bead-fixed single glazing – non-setting compound L40/250 Bead-fixed single glazing – tape and sealant L40/260 Bead-fixed single glazing – extruded gasket L40/310 Bead-fixed single glazing – tape, sealant and trim L40/330 Bead-fixed single glazing – capping L40/350 Bead-fixed single glazing – curing compound and trim L40/370 Bead-fixed insulating glass units – insert gasket sections L40/371 Bead-fixed insulating glass units – cellular adhesive/ mastic tape L40/372 Bead-fixed insulating glass units – loadbearing tapes/ synthetic rubber and sealant capping L40/380 Bead-fixed insulating glass units – solid bedding, outside bead L40/381 Bead-fixed insulating glass units – solid bedding, inside bead L40/40 Putty-fronted single glazing L40/410 Single glazing into grooves – extruded rubber/ PVC sections L40/430 Single glazing into grooves – non-setting compound L40/450 Single glazing into grooves – sealant capping L40/470 Zipper gasket glazing L40/490 Single-sided gasket glazing L40/50 Bead-fixed single glazing L40/530 Internal tape glazing L40/55 Bead-fixed insulating glass units – drained and ventilated bead L40/57 Bead-fixed insulating glass units – solid bedding, outside bead L40/58 Bead-fixed insulating glass units – solid bedding, inside bead L40/90 Internal tape glazing |
Specification data - Laminated glass sheets
General requirements | Glass generally. |
Third party accreditation | Cradle to Cradle Certified™ Silver. |
Laminate glass type | Safety/ privacy. |
Thickness | Manufacturer's standard.Guidance for specification option: Overall thickness dependent on configuration specified. Consult manufacturer for details. |
Outer leaf | Clearlite.Clearvision. |
Mid leaf | Not applicable. |
Inner leaf | As outer leaf. |
Interlayer to glass leaves | Minimum two PVB interlayers. |
Body colour | As interlayers to glass leaves.Guidance for specification option: Colour and quantity of interlayers will determine final overall colour. |
Pattern | Transparent. |
Performance requirements | |
Light | Manufacturer's standard.Guidance for specification option: Light transmission data is dependent is overall configuration specified; consult manufacturer's literature for details. |
Solar control | Manufacturer's standard.Guidance for specification option: Energy absorption data is dependent is overall configuration specified; consult manufacturer's literature for details. |
Total shading coefficient | Manufacturer's standard. |
Fire performance | |
Integrity | Manufacturer's standard.Guidance for specification option: Consult manufacturer for details. |
Insulation | Manufacturer's standard.Guidance for specification option: Consult manufacturer for details. |
Radiation | Manufacturer's standard.Guidance for specification option: Consult manufacturer for details. |
Sound attenuation | Manufacturer's standard.Guidance for specification option: Consult manufacturer for details. |
Impact resistance | Manufacturer's standard. |
Additional requirements | Guidance for specification option: All conventional processing options available for laminated glass can be applied to Stratobel Colour. In case of use in an external application, thermal absorption of some colours must be checked with the manufacturer. Insert requirements, or delete this property. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
Literature
Stratobel Security, high security laminated glass against attack, bullet and blast by AGC
Stratobel Security Performance Values
