Revolution 54, 100 mm Tech Panel - Media Walls

Name: Revolution 54, 100 mm Tech Panel - Media Walls
Brand: Optima
SKU: u2LArmzSEuM2Wh2aehdFek

Verified by manufacturer 6 months ago

Optima

Third party certifications:

BM Trada
Certificate type

Three dimensional Tech Panel compatible with Optima glass partitioning systems.

Jump to:

+44 (0)1494 492725 Website

Application

The Tech Panel designed to fully integrate with Optima Revolution 54 glazing system, allowing the use of room booking systems, lighting and temperature control within a meeting room.

Suitable applications include conference spaces and meeting rooms for office buildings and workplace environments.

Description

Tech Panels easily integrate with power and data requirements while guaranteeing continued high acoustic performance.

The 100 mm Tech Panel, when used within the Revolution 54 glazing system, creates a three dimensional “picture frame” style for added cavity depth and improved conduit capabilities.

Features and benefits:

Easily integrate your room booking device into the panel with all power and data requirements readily available.
Control the lighting with automatic sensors or standard switches from the same hub.
Heating and air conditioning can be located within the panel for a one-stop approach.
RFID lock access can ensure that only those with the permitted level of security can enter the room.
Available in a selection of finishes including powder coated or anodized aluminium, face-laminated timber and back-inked glass.
Retains the acoustic integrity of the room.
Conceals all power and data cables required for electrical switches and devices embedded within the Tech Panel face.

General information

Color	Silver Other
Finish	Anodized Laminated Powder-coated
Material	Glass Aluminium
Warranty description	Ten year Guidance for specification option: See Warranty Policy literature for exact details.

Uniclass	Pr_25_71_57_60 Partition panelsPrimary

Specification data - Partition panels

Third party accreditation	BM Trada certified.
Unit size	-
Thickness	100 mm.
Panel partition type	Media wall/ technology panel.
Solid panels	-
Finish and colour	Powder coated. Guidance for specification option: Insert requirements. Face-laminated timber. Guidance for specification option: Insert requirements. Anodized aluminium. Back painted glass. Guidance for specification option: Insert requirements.

Configuration	As drawing. Guidance for specification option: Insert drawing reference number. As schedule.

Sustainability data

Country of product manufacture	United Kingdom
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	26.1 kg CO₂ eq/m² Self declared Guidance for specification option: See Environmental Product Declaration for LCA data.
