Q-BOX Roller Blinds - Roller Blinds

Name: Q-BOX Roller Blinds - Roller Blinds
Brand: Bandalux Industrial SA
SKU: dTGwrEAhMTxKnPRGgxhkqG

Verified by manufacturer 1 month ago

Q-BOX 55

Bandalux Industrial SA

Third party certifications:

ISO 45001 Health and Safety Management
Certificate type
ISO 9001 Quality Management
Certificate type
QA Certificate
Certificate type
ASTM
Certificate type
GreenGuard Gold
Certificate type
EPD
Certificate type

Roller blinds with an aluminium cassette with easy ceiling, wall or recess installation.

Jump to:

+(34) 938 615 179 Website

Application

Suitable for indoor use, with easy ceiling, wall or recess installation.

Description

Q-Box is the indoor roller blinds with a compact box system and the ideal match for any style. As a result, this system is commonly found in hospitals and other buildings that require a simple aesthetic. This system affords an easy and quick installation on the ceiling or wall.

Features and benefits:

A subdued and refined look that fits seamlessly into any room.
100% aluminium compact cassette.
Easy ceiling, wall or recess installation.
Modern look fitting into the ambiance of the room.
Box available in three sizes.
Wide range of fabrics.
Minimal space between the box and the fabric reduces the entrance of light.
Convenience and ease when operating the blind.
Chain or motor operation.
Three year warranty.
Child safe system.
CE marked.

General information

Color	White Black Grey Brown Ivory Other Show more
Finish	Anodized Lacquered
Material	Fabric Aluminium
Shape	Rectangle Square
Width	Bespoke
Height	Bespoke
Warranty description	Three year

Uniclass	Pr_30_59_07_72 Roller blindsPrimary Pr_30_59_07_26 External roller blinds
CAWS	N10/240 Blinds N10/70 Blinds

Specification data - Roller blinds

Standards	To BS EN 13120.
Position	Internal to wall. Internal to ceiling. Internal to inner recess.
Dimensions (minimum width x depth)	- Manufacturer guidance Consult manufacturer and insert requirements.
Headrail	-
Material	Aluminium.
Blinds	-
Material	Fabric. Guidance for specification option: Consult manufacturer's literature and insert requirements.
Blackout function	Required. Guidance for specification option: Consult manufacturer and insert requirements. Not required.
Finish	- Manufacturer guidance Consult manufacturer's literature and insert requirements.
Colour	- Manufacturer guidance Consult manufacturer's literature and insert requirements.
Pattern	Digital Printing. Guidance for specification option: Consult manufacturer and insert requirements. Not required.
Tube	-
Material	Extruded aluminium.
Diameter	Ø28 mm. Ø32 mm.
Tube covers	-
Material	Extruded aluminium.
Colour	White, RAL 9016. Anodized Aluminium. Black, RAL 9011. Brown, RAL 8019. Grey, RAL 9006. Light Ivory, RAL 1013.
Operation	Manual, chain. Guidance for specification option: Minimum shade width: 350 mm. Motor, Bandalux Ø25 24 V Radio. Guidance for specification option: Minimum shade width: 540 mm. Motor, Bandalux Ø25 24 V Battery. Guidance for specification option: Minimum shade width: 530 mm. Motor, Somfy Roll Up WT 24 V. Guidance for specification option: Minimum shade width: 370 mm. Motor, Somfy Roll Up RTS 24 V. Guidance for specification option: Minimum shade width: 400 mm. Manufacturer guidance May vary depending on fabric. Consult manufacturer for details.
Mechanism endurance	To BS EN 13120, class 3.
Accessories	Not required. Personalization.

Bottom bar	Extruded aluminium.
Components	White, RAL 9016. Anodized Aluminium. Black, RAL 9011. Brown, RAL 8019. Grey, RAL 9006. Light Ivory, RAL 1013. Show more Manufacturer guidance Components colour. Cassette, chains, accessories and hembar in the same matching RAL colour to cassette.
Cassette size	55 mm.
Bottom rail design	Hidden bottom rail, Ø20 mm. Guidance for specification option: Provided as standard. Hidden bottom rail, teardrop. Guidance for specification option: Incompatible with Polyscreen® 314. Maximum width: 2500 mm. Visible bottom rail, Slim 25. Guidance for specification option: Maximum width: 2500 mm.
Operating system	Double drop, 2 operations.
Gap	8 mm. Manufacturer guidance Gap between the cassette and the fabric.

Sustainability data

Contains Red List materials	No
Country of material origin	Spain
Country of product manufacture	Spain
Material	Fabric Aluminium
Recyclability	Yes, Aluminum and Fabrics Guidance for specification option: Aluminum and Stainless Steel is 100% recyclable, an un-limited number of times, without losing or diminishing its chemical or mechanical characteristics. For this reason, the life cycle of an aluminum or stainless steel product tend to be circular, this concept being called “cradle-to-cradle”, currently used to reach an efficient economy in the use of resources, that takes advantage of all materials at the end of their useful life as raw materials.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	95 % Guidance for specification option: Bandalux’s extruded aluminum profiles and tubes have 95% recycled content. Bandalux’s laminated aluminum has between 45% and 65% recycled content. 90% or our contract fabrics collection has 2% up to 100% recycled content.
