Puracore 17.5 mm Aluminium Honeycomb Liner Panel

Name: Puracore 17.5 mm Aluminium Honeycomb Liner Panel
Brand: Gilcrest Manufacturing
SKU: nYQeHfoB9gpKQPFZYmPDq3

Verified by manufacturer today

Gilcrest Manufacturing

Product certifications:

FM Approved
Certificate type
EPD
Certificate type

Puracore 17.5 mm Aluminium Honeycomb Liner Panel

Jump to:

+44 (0117) 316 7020 Website

Application

Internal cleanroom use.

Description

Our Puracore 17.5mm Aluminium Honeycomb Lining Panel is an effective single-wall option for any class of cleanroom. The secret extrusion design allows for simple installation and no surface fixings.

Features a secret fixing extrusion for simple installation and no surface fixings
Perfect for upgrades to existing facilities as they can go against blockwork or stud walls
Non-shedding core
Stackable (Has been used on walls up to 18m high before)

General information

Color	White
Finish	Anti-microbial Manufacturer guidance Wide range available.
Material	Stainless steel Aluminium
Shape	Rectangle Square Other
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Ten year

Uniclass	Ss_25_12_65_65 Panel partition systemsPrimary Ss_25_10_30_70 Rigid sheet partition systems
CAWS	K30/135 Relocatable partition/ ceiling system K30/130 Relocatable partition system K30/10 Relocatable partition system

Specification data - Panel partition systems

Classification data
Finish	Aluminium powder coated. P.E.T. PVC-U Laminate. Polyester. Primer painted. Stainless steel.
Fire performance:	Class 'O'.
Fixing type	Batten fix to wall. Direct fix to wall.
Panel external face	0.7 mm galvanized steel substrate with specified finish.
Core	16.3 mm thick (½”) Aluminium Honeycomb 3003 Grade.
Length	Various up to 3000 mm.
Width	Various up to 1200 mm.
Thickness	17.5 mm.
Product Reference	17.5 mm Lining Panel
Weight	10.66 kg/m².

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Stainless steel Aluminium
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Certified
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 48.04
Recyclability	Can be recycled as scrap metal
Recycled content As defined in clause 7.8 of BS EN ISO 14021	35 %
