PourFlex Linear - Wet Room Drain

Verified by manufacturer 18 days ago

Pourflex Linear (SDPF.0700)

WM | Wetroom Materials Variant:

A linear wet room drainage system.

Jump to:
+44 (0)1332 840820 Website

Application

Suitable for low-profile wet rooms with poured or plastered floorings such as epoxy resin and micro cement.

Description

A linear wet room drainage system manufactured specifically for poured floors such as resin, micro cement and troweled floors such as tadelakt. The PourFlex Linear drain allows for a wet room to be created without any visible metal or grout lines.


Features and benefits:

  • 100% waterproof.
  • Designed for poured floors.
  • Ten year guarantee.
  • Easy to install.
  • Level floor access achievable.
  • Freestanding placement.
  • Pressed stainless steel body.
  • Edges can be sanded to suit floor thickness.
  • Flexible placement.

General information

Color

White

Material

Stainless steel

Plastic

Shape

Rectangle

Length

813 mm

Guidance for specification option:

Visual length of 700 mm.

913 mm

Guidance for specification option:

Visual length of 800 mm.

1013 mm

Guidance for specification option:

Visual length of 900 mm.

Width

164 mm

Height

90 mm

Manufacturer guidance

Drain depth.

Warranty description

Ten year

Uniclass

Pr_65_52_24_28 Floor channelsPrimary

CAWS

R11/315 Floor drains

R11/5 Floor drains

Specification data - Floor channels

Standard

To BS EN 1253.

Body

-

Material

Stainless steel.

Cover or grating

-

Cover or grating type

Solid covers.

Guidance for specification option:

Poured floor applied onto PourFlex panel.

Material

Cast solid surface and stainless steel.

Water trap

50 mm.

Manufacturer guidance

Water trap height.

Capacity

32 L/min.

Dimensions

813 x 164 x 90 mm.

Guidance for specification option:

L x W x D.

Sustainability data

Material

Stainless steel

Plastic

Literature

SC_WM_SD_PF_SDPF.0700 Datasheet

SC_WM_SD_PF_SDPF.0700 Datasheet

SC_WM_SD_PF_SDPF.0800 Datasheet

SC_WM_SD_PF_SDPF.0800 Datasheet

SC_WM_SD_PF_SDPF.0900 Datasheet

SC_WM_SD_PF_SDPF.0900 Datasheet
