Plain Top Road Stud
Verified by manufacturer 4 months ago
Aluminium Smooth Road Stud (400-102)
Aluminium Smooth Road Stud (400-102)
Plain Top road studs.
Application
- Pedestrian crossing points.
- Parking bays.
- Boundaries.
Description
Aluminium road studs, or pelistuds, are suitable for marking out pedestrian crossing points, parking bays, and boundaries. Made from aluminium for long-lasting performance, it features a fishtail shank and bevelled edge.
Stainless steel serrated surface road studs, or pelistuds for long-lasting performance, featuring a chisel shank and bevelled edge, are suitable for marking out pedestrian crossing points, parking bays, and boundaries.
Sizing Guide:
Aluminium Plain Stud w/ Fishtail shank - 75mm high
Stainless Steel Plain Stud w/ Fishtail shank - 70mm high
Stainless Steel Plain Stud w/ Chisel- 70mm high
General information
Color | Silver |
Finish | Matt |
Material | Stainless steel Aluminium |
Shape | Square |
Length | 100 mm |
Width | 100 mm Guidance for specification option: Diameter |
Height | 70 mm 75 mm |
Warranty description | One year |
Uniclass | |
CAWS | Q10/415 Demarcation units |
Specification data - Tactile paving studs
Material | Aluminium. |
Profile | Plain. |
Size | 100 x 100 x 75 mm. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
Recyclability | Should the need to recycle the studs arise, all material options can be melted down and reused again. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Literature
Aluminium Plain Top Road Stud - Datasheet
Stainless Steel Plain Top Road Stud - Datasheet
