Marcato Toilet Cubicles

Name: Marcato Toilet Cubicles
Brand: Washroom Washroom Ltd
SKU: 5YrzEFYL4YH2DndTPs8Wno

Verified by manufacturer 4 months ago

Toilet cubicles with solid grade laminate doors and partitions.

Jump to:

Application

Suitable for use as a toilet, shower or changing cubicle.

Features and benefits:

Available with 2100 mm overall height as standard.
The flush-fronted and rebated finish ensures that division panels and doors meet edge-to-edge for maximum privacy.
Optional floor-to-ceiling cubicles with minimal floor clearance for increased privacy.

Finish	- Manufacturer guidance Flush fronted and rebated.
Material	Solid grade laminate (SGL) Guidance for specification option: 20 mm.
Size	- Manufacturer guidance Floor Clearance 100 mm. Width Range 1500 - 1800 mm. Height 2100 mm o/a as standard but with options to extend to a full floor to ceiling system.
Width	- Manufacturer guidance 1500–1800 mm.
Height	2100 mm
Warranty description	One year Guidance for specification option: From practical completion.

Uniclass	Ss_25_12_60_60 Panel cubicle systemsPrimary
CAWS	K32/10 Panel cubicles K32/120 Panel cubicles

Product range	Marcato

Panels	13/20 mm solid grade laminate (SGL).
Panel supports	Satin anodized aluminium pedestal legs. Guidance for specification option: Tubular and rounded-off design, manufactured from satin anodized aluminium and fixed to partition panel. Adjustable to suit uneven floor levels.
Pilasters	20 mm solid grade laminate (SGL).
Doors	20 mm solid grade laminate (SGL).
Lippings	Vertical edges rebated to create flush finish. Manufacturer guidance Vertical edges are rebated to enable doors to close flush with the adjacent pilasters. All other edges are machined to a smooth profile. Exposed edges machined to a smooth finish with radiused safety corner details to doors and pilasters.
Hardware	Stainless steel fall closed hinges. Coat hook. Easily operable indicator bolt with full length satin anodized aluminium channels.
System accessories	Handrail. Grab rail. Manufacturer guidance Cubicles are available in configurations to comply with Approved Document M (E&W), complete with outward opening doors. A standard stainless steel pull handle is supplied to the outside face of all outward opening cubicle doors. Complementary grab rails and hand rail are also available.
