Harmony Drift - Acoustic Panel

Name: Harmony Drift - Acoustic Panel
Brand: Soundtect
SKU: oBUFNHba69454di6RmaLMV

Verified by manufacturer 7 days ago

Soundtect

Slatted acoustic wall and ceiling covering.

Jump to:

+44 (0)203 0402939 Website

Application

Suitable for acoustic wall and ceiling applications in interior environments including institutional, commercial, wellness, and public settings.

Description

The Drift panels are used for wall and ceiling applications, allowing for flexible configurations that incorporate both Freestyle standard and Timba wood effect colour options. Pre-cut Freestyle battens are attached to Freestyle felt backing with 10 mm spacing, enabling installation on both curved and straight surfaces.

The acoustic panels are designed to support reverberation and sound control.

Features and benefits:

Elevated design potential.
Flexible design options for various applications.
Available in any configuration from the 24 Freestyle colour range and other wood finishes on request.
Maximum size panel 600 x 600 mm, with customizable sizes available upon request.
Provides sound absorption and reverberation control on walls and ceilings.
Integrated with Soundtect acoustic technology.
100% recyclable and environmentally friendly.
Made from 100% polyester.
Contains up to 70% post-consumer recycled content, with a minimum of 50%.
Low VOC emissions.
Fire classification rating to EN 13501, Class B-s1, d0.
Manufactured by Soundtect and in an ISO 14006 certified facility.
Standard battens are 25 mm in width and 20 mm in depth, with sizes available upon request.

General information

Color	Beige Black Blue Brown Green Grey Orange Red White Yellow Show more
Finish	Textured
Material	Polyester fibre (PET)
Shape	Rectangle Square
Length	600 mm
Width	600 mm
Height	25 mm
Warranty description	Ten year

Uniclass	Pr_35_93_13_80 Sound attenuator infill unitsPrimary Ss_25_25_75_05 Acoustic panel lining systems
CAWS	K13/170 Acoustic panel lining K13/170 Acoustic panel lining K40/20 Board-suspended ceiling systems K40/135 Board-suspended ceiling system

Specification data - Sound attenuator infill units

Classification data
Form	Panel. Raft.
Rigidity	Rigid.
Application	Ceiling mounting. Guidance for specification option: Installation: Screws to ceiling. Wall mounting. Guidance for specification option: Installation: Contact adhesive to wall.
Material	Polyester.
Material density	10 mm, 2 kg/m². 20 mm, 4 kg/m².
Acoustic performance	-
Purpose	Absorber.
Sound absorption	NRC 0.85. Guidance for specification option: Based on 20 x 30 slats with 10 mm spacing.
Fire performance	-
Reaction to fire	To EN 13501, B-s1, d0.
Dimensions	-
Size (length x width)	600 x 600 mm. Custom. Guidance for specification option: Available in custom sizes. Consult manufacturer for details and insert requirements.
Thickness (overall)	25 mm.
Profile	Linear.
Edges	Square.
Surface pattern	Solid.
Colour	Azalea. Salsa. Flamenco. Cha cha. Rumba. Conga. Cornfield. Lambada. Red earth. Coral. Calypso. Jive. Azure. Twist. Bolero. Tango. Lagoon. Quickstep. Olive. Moss. Disco. Zumba. Bark. Vogue. Passo. Mambo. Polka. Contemporary. Ballet. Hip hop. Waltz. Chalk. Latin. Other. Guidance for specification option: Available in a range of Timba wood effect colours. Consult manufacturer for details and insert requirements.
Colour fastness	Colourfastness to Light, AATCC16(3), Class 4.5.
Noise reduction coefficient (NRC)	0.85. Guidance for specification option: Based on 20 x 30 slats with 10 mm spacing.
MoistureContent	Polyester fibre when exposed to an atmosphere of 50°C at 90% relative humidity for four days showed moisture absorption of less than 0.03% by weight. Polyester is not affected by moisture.

Sustainability data

Contains Red List materials	No
Country of material origin	China
Country of product manufacture	Hong Kong
Material	Polyester fibre (PET)
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	70 %
