Class Bespoke - Acoustic Panel

Name: Class Bespoke - Acoustic Panel
Brand: Soundtect
SKU: wFY1Jzgs2Lg2CFoowcg2ue

Verified by manufacturer 2 days ago

Soundtect

Acoustic fabric wrapped wall and ceiling panels.

Jump to:

+44 (0)203 0402939 Website

Application

Acoustic Panel for Wall and ceiling applications

office
break out areas
restaurants
lecture hall
education
gymnasium
public area
lecture hall
auditoriums
home cinema
meeting room
hospitality
swimming pool area
spa
medical centre
airport
library
hotel
reception area
atrium
dining hall
assembly hall
classroom
sales area

Description

The bespoke fabric wrapped range allows you to bring new ideas to life with our proven highly-effective and beautifully-engineered acoustic panels which we will make to order in any shape, size, depth and colour.

Features and benefits:

Manufactured from highly effective, recycled, acoustic materials.
Incredible versatility.
Available in a wide range of colours.
Create bespoke designs in specific corporate or design colours.
Suspend from the ceiling or install on the wall.
Excellent sound absorption.
Finely turned reverberation thanks to Soundtect’s pioneering acoustic technology.
Environmentally friendly and recyclable, Class Bespoke Acoustic Panels are ideal for projects when there is an eco-conscious consideration to be made.
Manufactured by Soundtect®
Independently certified
Composition: 100% polyester.
Low VOC.
Colourfastness to Light, AATCC16(3), Class 4.5
BS EN ISO 354:L2003.
Certified 100% recyclable.
PET with over 50% recycled content.

10-12 weeks sea shipment

2-3 air freight

General information

Color	Other Manufacturer guidance Unlimited colour range.
Material	Polyester fibre (PET)
Shape	Other Square Rectangle Octagon Hexagon Kite Trapezium Triangle Show more
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Ten year

Uniclass	Pr_35_93_13_80 Sound attenuator infill unitsPrimary Ss_25_25_75_05 Acoustic panel lining systems
CAWS	K40/135 Board-suspended ceiling system K40/20 Board-suspended ceiling systems K13/170 Acoustic panel lining K13/170 Acoustic panel lining

Specification data - Sound attenuator infill units

Form	Raft. Baffle. Panel.
Application	Ceiling mounting. Wall mounting.
Material	Polyester.
Acoustic performance	-
Sound absorption	To EN ISO 11654: NRC: 0.95 Class A.
Fire performance	-
Reaction to fire	BS1 DO. Suitable for use in Class1 and Class 0.
Dimensions	-
Size (length x width)	- Manufacturer guidance Bespoke, consult manufacturer for details and insert requirements.
Thickness (overall)	- Manufacturer guidance Bespoke, consult manufacturer for details and insert requirements.
Colour	- Manufacturer guidance Bespoke, consult manufacturer for details and insert requirements.

MoistureContent	Polyester fibre when exposed to an atmosphere of 50°C at 90% relative humidity for four days showed moisture absorption of less than 0.03% by weight. Polyester is not affected by moisture.
Colour fastness	Colourfastness to Light, AATCC16(3), Class 4.5.

Sustainability data

Contains Red List materials	No
Country of material origin	China
Country of product manufacture	China
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	50 %
