Class Wall Panels - Acoustic Panel
Verified by manufacturer 2 days ago
Acoustic wall panel
Application
Acoustic Panel for Wall and ceiling applications
- office
- break out areas
- restaurants
- lecture hall
- education
- gymnasium
- public area
- lecture hall
- auditoriums
- home cinema
- meeting room
- hospitality
- swimming pool area
- spa
- medical centre
- airport
- library
- hotel
- reception area
- atrium
- dining hall
- assembly hall
- classroom
- sales area
Description
Manufactured from environmentally-sound material, the Class wall panels come in three colours and provide a cost-effective but high-performance solution to a range of acoustic challenges.
Using the three colour options, the user can create a feature wall or geometric pattern for interest.
Features and benefits:
- Mount on walls.
- Arrange and combine in various formation.
- Suspend from ceilings.
- Layer in varying depths to create dramatic spaces.
- Using the same tried and tested recycled PET bottles as the existing range.
- Soundtect brackets allows easy installation.
- Cost effective solution for large installations.
- Installation flexibility for walls and ceilings.
- Sustainable design.
- Composition: 100% polyester.
- Low VOC.
- Colourfastness to Light, AATCC16(3), Class 4.5
- BS EN ISO 354:L2003.
- Certified 100% recyclable.
- PET with over 50% recycled content.
10-12 weeks sea shipment
2-3 air freight
General information
Color | Black Grey White |
Finish | Textured |
Material | Polyester fibre (PET) |
Shape | Square Rectangle |
Length | 600 mm 1200 mm |
Width | 300 mm 600 mm |
Height | 50 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | K13/170 Acoustic panel lining K13/170 Acoustic panel lining |
Specification data - Acoustic panel lining systems
Panelling | |
Type | Individual panels. |
Surface material | Polyester. |
Surface finish | Smooth. |
Size: | 300 x 1200 x 50 mm. 600 x 600 x 50 mm. 600 x 1200 x 50 mm. |
MoistureContent | Polyester fibre when exposed to an atmosphere of 50°C at 90% relative humidity for four days showed moisture absorption of less than 0.03% by weight. Polyester is not affected by moisture. |
FireRating | BS1 DO. Suitable for use in Class1 and Class 0. |
Acoustic performance | To EN ISO 11654: NRC: 0.95. |
Colour fastness | Colourfastness to Light, AATCC16(3), Class 4.5. |
Colour: | Ash. Charcoal. White. |
Sustainability data
Contains Red List materials | No |
Recyclability | 100% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 70 % |
Literature
Class Specification sheet
Class acoustic data
Class wall installation guide
Class care and maintenance
