Circle Rafts - Acoustic Panel

Name: Circle Rafts - Acoustic Panel
Brand: Soundtect
SKU: dUiyAjmsxLKNeFmGA3UGL2

Verified by manufacturer 2 days ago

Soundtect

Third party certifications:

QA Certificate
Certificate type
VOC Content test Certificate
Certificate type
SRL
Certificate type

Suspended Circular Acoustic ceiling raft

Jump to:

BOS

+44 (0)203 0402939 Website

Application

Acoustic wall and ceiling applications:

office
break out areas
restaurants
lecture hall
education
gymnasium
public area
lecture hall
auditoriums
home cinema
meeting room
hospitality
swimming pool area
spa
medical centre
airport
library
hotel
reception area
atrium
dining hall
assembly hall
classroom
sales area

Description

Class Circles acoustic ceiling rafts are both beautiful and functional. Offering understated elegance for ceiling applications, Class Circles add a new dimension to our range.

Suitable for residential and commercial applications, Available in three colours and 1200 and 800 mm diameters, the acoustic panels can be used to create floating ceilings which absorb sound and enhance sound quality.

Reverberation is reduced by offering Class A absorption to increase speech intelligibility in a specific area while reducing background sound noise levels.

Features and benefits of Class acoustic rafts:

A better way to transform open, sound-challenged spaces into more comfortable environments.
Endless installation and design possibilities.
Soundtect's clever suspension system allow easy installation.
Cost effective solution for large installations.
Global Greentag certified and made from recycled materials, a sustainable design for environmentally conscious projects.
Recyclable.
Composition: 100% Polyester.
Low VOC.
Colourfastness to Light, AATCC16(3), Class 4.5.
BS EN ISO 354:L2003.
Certified 100% recyclable.
Composition: 100% polyester fibre (PET) 70% recycled.

10-12 weeks sea shipment

2-3 air freight

General information

Color	Black Grey Red White
Finish	Textured
Material	Polyester fibre (PET)
Shape	Circle
Length	800 mm 1200 mm Manufacturer guidance Diameter
Width	800 mm 1200 mm
Height	50 mm
Warranty description	Ten year

Uniclass	Pr_35_93_13_80 Sound attenuator infill unitsPrimary
CAWS	K40/135 Board-suspended ceiling system K40/20 Board-suspended ceiling systems

Specification data - Sound attenuator infill units

Form	Panel.
Application	Ceiling mounting.
Material	Polyester.
Acoustic performance	-
Sound absorption	To EN ISO 11654: NRC: 0.80.
Fire performance	-
Reaction to fire	BS1 DO. Suitable for use in Class1 and Class 0.
Dimensions	-
Size (length x width)	800 mm diameter. 1200 mm diameter.
Colour	Ash. Charcoal. Red White.

MoistureContent	Polyester fibre when exposed to an atmosphere of 50°C at 90% relative humidity for four days showed moisture absorption of less than 0.03% by weight. Polyester is not affected by moisture.
Colour fastness	Colourfastness to Light, AATCC16(3), Class 4.5.

Sustainability data

Contains Red List materials	No
Country of material origin	China
Country of product manufacture	Hong Kong
Material	Polyester fibre (PET)
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	50 %
