Edmo Scissor Lift
Verified by manufacturer 21 hours ago
Single scissor
Single scissor
Hydraulic table lift that can be adapted into a goods or passenger lift, for loads up to 2000 kg.
Application
Internal or external lifting requirements, rated loads up to 10 000 kg.
Description
Hydraulic table lift that can be adapted into a goods or passenger lift, for loads up to 2000 kg.
Features and benefits:
- Range of customizations, options and extras, including finishes, materials and colours.
- Maximized space: the platform size is the footprint.
- Integral power pack.
- Single, double or triple scissor models.
- Use with ramp or pit at closed height for flush finish.
Safety features:
- Safety edge perimeter bars.
- Safety spacing – no trapping points.
- Armoured hydraulic hoses with burst valves.
- Overload protection – tested to 130%.
- Mechanical props/locks for maintenance.
- Hydraulic cylinders with high pressure seals.
- Microprocessor controlled.
- Adjustable flow control valve.
General information
Color | Orange Blue Other |
Shape | Rectangle |
Uniclass | |
CAWS | X12/110 Vertical lifting platform systems X12/110 Vertical lifting platform systems |
Specification data - Vertical lifting platforms
Rated load (minimum) | Manufacturer's standard. Guidance for specification option: Varies with model specified; also Capacity below for load ranges. |
Drive type | Hydraulic cylinder system. |
Carriage type | Table lift. Goods lift. Guidance for specification option: Consult manufacturer for details of rail placement etc. Passenger lift. Guidance for specification option: Consult manufacturer for details of rail placement etc. |
Carrier | |
Frame material | Manufacturer's standard. |
Frame finish | Manufacturer's standard. |
Frame colour | Orange. Bespoke. Guidance for specification option: Consult manufacturer for options and insert requirements. |
Carrier floor | |
Dimensions | |
Width (minimum) | Manufacturer guidanceInsert requirements, 600–2000 mm. |
Depth (minimum) | Manufacturer guidanceInsert requirements, 600–5000 mm. |
Material | Manufacturer's standard. Bespoke. Guidance for specification option: Consult manufacturer for options and insert requirements. |
Colour | Blue. Bespoke. Guidance for specification option: Consult manufacturer for options and insert requirements. |
Electrical supply | Three-phase, integral power pack. Guidance for specification option: Standard, 380–500 V, 50 Hz. Note that sizes/ capacities will require a remote power pack; consult manufacturer for details. Three-phase, remote power pack. Single-phase power pack. Guidance for specification option: Consult manufacturer for details and insert requirements. |
Control device type | Remote buttons, standard. Stanchion-mounted buttons, standard. Remote buttons, bespoke lettering. Stanchion-mounted buttons, bespoke lettering. Remote buttons with Braille. Stanchion-mounted buttons with Braille. Bespoke. Guidance for specification option: Consult manufacturer for options and insert requirements. |
Control features | None. Level announcer. Level display. |
Accessories | Manufacturer guidanceConsult manufacturer for details of specific features, materials, colours or design not listed above and insert requirements. Note that rails are covered by the Carriage type specified. |
Capacity | 500–10 000 kg. Guidance for specification option: 600–3600 mm travel. |
Ramp | Not required (pit). Required. Manufacturer guidanceConsult manufacturer for appropriate sizes. |
