Aritco 7000 Passenger Platform Lift - Same Side Entry and Exit Doors
Verified by manufacturer over a year ago
The Aritco 7000 platform lift - ideal for commercial environments, offering security and minimal disruption once it is installed.
Description
Passenger platform lift designed to complement any commercial or public environment. The 7000 platform lift is most popular for use in schools, office blocks, hospitals, care homes and retail shops due to its size and easy compliance with the Equality Act (DDA) for wheelchair and disabled access.
The patented screw-and-nut drive system in the 7000 platform lift offers a safe, quiet and environmentally friendly solution, running up a mast behind the platform.
Completely self-contained, the 7000 eliminates the need for a separate machine room or pump box housing, and doesn't need a head fixing, ideal for restricted or listed buildings. Operation inside the lift is by continuous pressure, and outside using a single touch-button to call the lift to the floor.
Meets the requirements of Building Regulations (E&W) Approved Document M and BS 8300, as well as helping to meet obligations under BS EN 81-41 and the Equality Act (formerly the DDA).
Features:
- Up to 13 m (six stops) with up to two doors per floor.
- Eight platform sizes.
- Internal installation.
- Safety edge, alarm system and telephone.
- Emergency battery lowering.
- Small footprint.
- Quiet and energy-efficient.
- 210 RAL colour and four glass shaft options.
- 50 mm pit or ramp.
Approvals/ accreditations:
- European machine directive 2006/42/EC.
- ISO 9001:2008.
- OHSAS 18001.
- CE Marked.
General information
Shape | Rectangular |
Color | White, grey, natural metal |
Finish | Powder coated |
Size | 1040 x 900 mm platform |
Uniclass | |
CAWS | X12/110 Vertical lifting platform systems |
Specification data - Vertical lifting platforms
Product Reference | Aritco 7000 |
Platform | - |
Size (w x l)/ rated load | 900 x 1040 mm, 410 kg1275 x 1160 mm shaft size, 1305 x 1190 mm structural opening. 900 x 1280 mm, 410 kg1275 x 1400 mm shaft size, 1305 x 1430 mm structural opening. 900 x 1480 mm, 410 kg1275 x 1600 mm shaft size, 1305 x 1630 mm structural opening. 900 x 1480 mm, 500 kg1275 x 1600 mm shaft size, 1305 x 1630 mm structural opening. 1000 x 1280 mm, 410 kg1375 x 1400 mm shaft size, 1405 x 1430 mm structural opening. 1000 x 1480 mm, 410 kg1375 x 1600 mm shaft size, 1405 x 1630 mm structural opening. 1000 x 1480 mm, 500 kg1375 x 1600 mm shaft size, 1405 x 1630 mm structural opening. 1000 x 1980 mm, 500 kg1375 x 2100 mm shaft size, 1405 x 2130 mm structural opening. 1100 x 1480 mm, 410 kgStandard, 1475 x 1600 mm shaft size, 1505 x 1630 mm structural opening. 1100 x 1580 mm, 500 kg1475 x 1700 mm shaft size, 1505 x 1730 mm structural opening. |
Console height | 1100 mmStandard. 2200 mm |
Handrails | AluminiumStandard. Stainless steel |
Flooring | Aluminium checkerplateRubber, black studdingRubber, blue studdingVinyl, beige mineralVinyl, blue mineralVinyl, classic beechVinyl, European oakVinyl, grey mineralStandard material. Vinyl, sand mineralBespokeConsult manufacturer and insert requirement. |
Destination buttons | BrailleComplies with BS EN 81-41. TactileStandard, complies with BS EN 81-41. |
Communication | AutodiallerIntercomTelephoneStandard. |
Shaft | - |
Construction | Insulated vinyl coated double skinned steel panelsStandard. Toughened and laminated glazed panelsAvailable in up to 2500 mm high. |
Colour | Clear glass (JT0)For glazed panels. Dark-tinted glass (JT5)For glazed panels. Frost glass (JT23)For glazed panels. RAL 9016Standard, white. RALInsert colour requirement, for steel panels. Tinted glass (JT16)For glazed panels. |
Doors | - |
Type | Double-hingedAutomatic. Fire doors60 minutes' fire and smoke resistance. GLStandard, glass and steel door with concealed door closer. HGHalf height, under 2 m travel only. |
Arrangement | As drawingInsert reference, available up to two sides per floor. |
Operation | AutomaticOpens when call button is pressed. Manual, concealed door closerStandard. |
Colour | RAL 9016Standard, white. RALInsert colour requirement. |
Glazing | Clear glass (JT0)Standard. Dark-tinted glass (JT5)Frost glass (JT23)Tinted glass (JT16) |
Handles | AluminiumStandard. Stainless steel |
Accessories | NoneDoor key switchExternal alarmFold-down seatLanding call stationLift position indicators on landingsPlatform destination indicatorRamped lift entryShaft lighting - LEDWireless remote call stations |
Standard product features | Size:
Technical properties:
|
Product Options | Size (w x l)/ rated load: - Power:
Three-phase power supply can be provided for 410 kg rated load models on request; consult manufacturer for details. |
BIM objects
NBS BIM object standard
This BIM object has been authored to meet the requirements of the NBS BIM object standard.
Find out more about the NBS BIM object standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | IFC2X3 | 3 |
 Revit | Revit 2016 | 4 |
