Comar 7 Aluminium Doorsets
Verified by manufacturer 15 hours ago
A range of high performance commercial doorsets available in a variety of profiles.
Application
Suitable for commercial applications such as retail, public buildings, schools and leisure facilities.
Description
A range of commercial doorsets available in a variety of profiles. Provides high performance in retail, public buildings, schools and leisure applications.
Accreditations:
- PAS 24:2022.
- Secured by Design.
General information
Color | Black Grey White Other |
Finish | Anodized Powder-coated |
Material | Aluminium |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Ten year Guidance for specification option:
30 year Guidance for specification option:
25 year Guidance for specification option:
Other Guidance for specification option:
|
Uniclass | |
CAWS | L20/480 Doorsets L20/520 Sliding doors L20/55 Doorsets L20/60 Doors |
Specification data - Aluminium doorsets
Doorset size | Guidance for specification option: Consult manufacturer and insert requirements. |
Performance | |
Intruder resistance | |
Minimum requirement | To PAS 24:2022. |
Frame | |
Material | Extruded aluminium profiles are of aluminium alloy 6063 T5 or T6 and comply with BS EN 12020-2:2001 and BS 755-9:2001. |
Threshold | Low aluminium threshold. |
Finish | |
Coating | Anodizing to BS EN 12373-1:2001.Polyester powder coating to BS 6496. |
Colour | Guidance for specification option: Consult manufacturer and insert requirements or omit. |
Installation fasteners | Guidance for specification option: Consult manufacturer and insert requirements or omit. |
Frame accessories | Guidance for specification option: Consult manufacturer and insert requirements or omit. |
Door leaf | |
Thickness | Guidance for specification option: Consult manufacturer and insert requirements or omit. |
Material | Extruded aluminium profiles are of aluminium alloy 6063 T5 or T6 and comply with BS EN 12020-2:2001 and BS 755-9:2001. |
Glazing | |
Type | Solid panel.Single glazed.Double glazed. |
Beading | |
Type | Internal.External. |
Material | Extruded aluminium profiles are of aluminium alloy 6063 T5 or T6 and comply with BS EN 12020-2:2001 and BS 755-9:2001. |
Finish | |
Coating | Anodizing to BS EN 12373-1:2001.Polyester powder coating to BS 6496. |
External colour | Guidance for specification option: Consult manufacturer and insert requirements or omit. |
Internal colour | Guidance for specification option: Consult manufacturer and insert requirements or omit. |
Film thickness (minimum) | 60 microns. |
Hardware | Axim HD80 Series Aluminium Tube Handle.Axim HD90 Series Aluminium Pad Handle.Axim HD91 Series Stainless Steel Pull Handle.Axim HD48 Stainless Steel Flush Pull Handle.Axim PH2100 Paddle Handle.Axim LK1800 Hook Lock.Axim LK-2100 Reversible Deadlatch.Axim LK2100 Dead Latch.Axim ES-2200 Electric Strike Series.Axim PR7085/ PR7095 Concealed Rod Crash Bar Exit Device.Axim PR7085P Concealed Rod Paddle Exit Device.Axim PR7095 Rim Mounted Crash Bar Exit Device.Axim PR7095P Rim Mounted Paddle Exit Device. |
Accessories | Guidance for specification option: Consult manufacturer and insert requirements or omit. |
Configuration | Rebated. Sliding. Sliding/ folding. Swing. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Aluminium |
Recyclability | Aluminium profile fully recyclable at end of life |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 70 % |
Literature
Comar life expectancies and warranties to BS 7543:2015
