Cavi60 Type WCA Cavicloser
Verified by manufacturer 8 months ago
Fire rated insulated, acoustic reduction structural cavity closer and DPC for wide cavities.
Application
Suitable for cavities up to 150 mm wide.
Description
One piece, fire rated, insulated, structural cavity closer and DPC for wide cavities.
Features and benefits:
- 60 minutes fire integrity rated vertically (Cavity Trays Ltd claims product has been tested to BS 476-20).
- Permits choice of frame positions.
- Includes anti capillary fins.
- Heavy duty body.
- Closer has its own anchoring ties.
- Acoustic reduction quality insulator.
General information
Color | White |
Material | PVC-U Guidance for specification option: Un-plasticized polyvinyl chloride compound. |
Shape | Rectangle |
Size | Manufacturer guidance70 mm x cavity width required within range. Available in lengths of 2.1 m, 3.0 m and to special order 3.6 m. |
Length | 3000 mm |
Width | 150 mm |
Height | 60 mm |
Uniclass | |
CAWS | F30/18 Cavity closers F30/180 Cavity closers |
Specification data - Plastics cavity closers
To fit cavity width | 100 mm.150 mm.__ mm.Manufacturer guidanceCan be supplied in width increments to provide a robust preformed solution for unusual widths and applications. |
Length (effective) | 2100 mm.3000 mm.3600 mm. |
ThermalConductivity | 0.033 W/mK. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | yes |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 100 % |
Literature
Protecting the Building Envelope Volume 28 (cavity tray, damp proofing, ventilation and cavity closers)
