Cavi240 Type CFIS cavity fire stop
Verified by manufacturer 7 months ago
Cavity fire stop.
Application
For horizontal and vertical use in cavities up to 90 mm wide.
Description
Fire rated, polythene sleeved. rock mineral wool, friction fit cavity fire and acoustic stop.
Features and benefits:
- 240 minutes fire integrity rated (Cavity Trays Ltd claims product has been tested to BS 476-20 by Warrington Fire Research Centre).
- Retained in position by compression (10 mm minimum).
General information
Color | Red |
Finish | Coated |
Shape | Rectangle |
Size | Manufacturer guidance[Size, 1200 x 100 x 50 mm] |
Length | 1200 mm |
Width | 100 mm |
Height | 50 mm |
Uniclass | |
CAWS | F30/18 Cavity closers F30/180 Cavity closers |
Specification data - Plastics cavity closers
To fit cavity width | Guidance for specification option: Insert requirements; up to 200 mm. |
Length | 1200 mm. Guidance for specification option: As standard. Contractor's choice. As drawings___. |
Thermal resistance | 2.37 m² K/W. Guidance for specification option: Insulation properties. |
ThermalConductivity | 0.035 W/m·K. Guidance for specification option: Insulation properties. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | yes |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 100 % |
Literature
Protecting the Building Envelope Volume 28 (cavity tray, damp proofing, ventilation and cavity closers)
