AT-FSD Series Motorised Air Transfer Fire Damper

Name: AT-FSD Series Motorised Air Transfer Fire Damper
Brand: BSB Engineering Services Limited
SKU: 5K3A4R6UERP67AHKtPgZFb

Verified by manufacturer 6 days ago

BSB Engineering Services Limited

Motorised fire damper designed to maintain fire compartmentation in the event of a fire whilst allowing for air movement in installations without ductwork.

Request BIM

01795 422609 Website

Application

For internal use in buildings .

Intended for installations without ductwork.
To be installed above protective doorways and in extended fire separations within ceiling voids.
May be used for dryline walls and masonry/concrete constructions.
Suitable for protected escape routes and areas with sleeping risk.

Requires access from one side of the fire separation wall only during installation.

Description

AT-FSD series ES rated motorised fire damper is designed to stop the spread of fire whilst maintaining air movement in installations without ductwork. Available in a range of sizes, it consists of a base damper housed within a fully welded galvanized steel sleeve. Its peripheral flange allows it to be fitted flush into the builders aperture using side fixings only whilst an optional non-vision grille provides a discrete appearance.

Features and benefits:

Reduced top and bottom flange.
Integral thermal fuse bracket.
Fire resistance tested to BS EN 1366-2.
ES classified to BS EN13501-3.
CE marked to BS EN 15650.
Available in sizes from 200mm wide x 175mm high up to 1000mm wide x 300mm high (aperture size).
Optional purpose made matching grille in standard RAL 9010 available.

General information

Color	Silver
Finish	Galvanized
Material	Steel
Shape	Rectangle Square
Length	360 mm Guidance for specification option: Allow 425 mm with cable bend. Manufacturer guidance Depth.
Width	Bespoke Guidance for specification option: Minimum: 200 mm. Maximum: 1000 mm.
Height	Bespoke Guidance for specification option: Minimum: 175 mm. Maximum: 300 mm.
