Aluminium Entrance Door - ADS 65 HD Gen2 - Heavy Duty Door System

Verified by manufacturer 6 months ago

Schueco UK Ltd

A door system achieving high weather performance and thermal insulation

Jump to:
+44 (0)1908 282111 Website

Application

For entrance and exit areas subject to heavy use with the highest requirements for stability and ease of use.

  • Internal use.
  • External use.
  • Residential projects.
  • Commercial projects.
  • Doors.
  • Healthcare.
  • Education.
  • Accommodation facilities.
  • Industrial buildings.

Description

Sophisticated door solution which meet high requirements in terms of weathertightness, thermal insulation and flexibility.


The second generation of the tried-and-tested Schüco ADS door 65 HD (Heavy Duty) door system in the 65 mm basic depth offers added benefits in terms of possible uses and designs thanks to optimized system properties and full compatibility with the Schüco modular system – all combined with efficient fabrication. This opens up more options for specifiers and fabricators for newbuilds and modernisations in commercial and residential construction.


Features and benefits:

  • Virtually identical work and fabrication processes to the tried-and-tested Schüco ADS 65 HD door system, along with the familiar machinery and tools, ensure simple, economical production and installation
  • Centre gasket concept optimized for fabrication.
  • Full compatibility with the Schüco modular system.
  • Different fittings types for design freedom.

General information

Color

Other

Guidance for specification option:

RAL colour.

Finish

Painted

Powder-coated

Anodized

Material

Aluminium

Glass

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Pr_30_59_24_02 Aluminium doorsetsPrimary

CAWS

L20/55 Doorsets

L20/480 Doorsets

Specification data - Aluminium doorsets

Configuration

Single-vent, inward opening, for use in facade.

Guidance for specification option:

Vent details specified separately below.

Single-vent and side section, inward opening, for use in facade.

Guidance for specification option:

Vent details specified separately below.

Single-vent, outward opening, for use in facade.

Single-vent and side section, outward opening, for use in facade.

Single-vent, inward opening, for use in glazing.

Single-vent and side section, inward opening, for use in glazing.

Single-vent, outward opening, for use in glazing.

Single-vent and side section, outward opening, for use in glazing.

Doorset size

-

Manufacturer guidance

Insert requirements.

Maximum height: 3000 mm; maximum width: 1400 mm.

Weight: Up to 200 kg.

Performance

-

Strength and durability

To BS EN 1192, Class 1.

Guidance for specification option:

  • Mechanical strength: Class 3.
  • Proof of durability: 200 000 cycles in accordance with DIN EN 12400.

Thermal

1.4 W/m²K.

Intruder resistance

-

Minimum requirement

-

Manufacturer guidance

Up to RC 2; insert requirements.

Application

-

Manufacturer guidance

Insert requirements.

Frame

-

Material

Aluminium.

Threshold

Aluminium.

PVC-U.

Automatic door gasket.

Easy-access door threshold.

Finish

-

Coating

Painted.

Powder coated.

Anodized.

Colour

-

Manufacturer guidance

Insert requirements based on Coating specified above. Consult manufacturer for options and/or further details.

Door leaf

-

Thickness

65 mm.

Glazing

-

Type

Double glazing.

Triple glazing.

Manufacturer guidance

Consult manufacturer for options and insert requirements.

Manifestation

-

Manufacturer guidance

Insert requirements or omit.

Finish

-

Coating

To match frame.

Texture

Manufacturer's standard.

External colour

To match frame.

Internal colour

As External.

Film thickness (minimum)

Manufacturer's standard.

Door accessories

-

Manufacturer guidance

Insert requirements or omit.

Hardware

-

Manufacturer guidance

Insert requirements.

Accessories

-

Manufacturer guidance

Consult manufacturer’s literature for details and insert requirements, or omit.

Vent

All around.

Flush-fitted.

Face-fitted.

Inward opening.

Outward-opening.

Show more

Watertightness

Class 7A.

Wind load resistance

Class C2.

Impact resistance

Class 1.

Sustainability data

Contains Red List materials

No

Country of material origin

Germany

Country of product manufacture

United Kingdom

Recyclability

cradle2cradle
