Showing 1-36 of 40
Ancon 25/14 Restraint System
Leviat
The Ancon 25/14 Restraint System ties an outer leaf of brickwork to a light steel frame.
Self-drilling, high-thread screws fix through the channel and rigid insulation board and into the steel. Stainless steel SD25 or basalt fibre Teplo-BF-CT 25 wall ties are located in the channel and built into the bed joints of the outer leaf of brickwork.
This system has been independently tested by Lucideon and is UKCA and CE marked. A Declaration of Performance is available to download from www.ancon.co.uk/approvals.
Ancon Acoustic Wall Ties
Leviat
Acoustic wall ties and frame cramps for connecting the leaves of a cavity wall while minimising the transfer of airborne noise and vibration.
Ancon CCB Cellular Clay Block Wall Ties
Leviat
Ancon has developed an innovative range of wall ties for use with cellular clay blockwork, where the horizontal bed joints are just 1mm. The range includes ties for internal wall junctions and internal/external cavity walls. They are manufactured from corrosion-resistant stainless steel and are suitable for use in housing and commercial applications.
Ancon CFS+ Stainless Steel Concrete Fixing Screw
Leviat
Stainless steel concrete fixing screw developed for use with the Ancon 25/14 Channel System
Ancon KSN Anchor Reinforcement Continuity Systems
Leviat
The KSN system comprises of internally-threaded anchors which are cast into the wall and, during construction of the adjoining slab, accept continuation bars prepared with a Bartec parallel-thread. This is fastest and safest system.
There is no on site bar straightening and virtually no restriction on bar length, so EC2 lap lengths are easily accommodated. A standard timber carrier allows multiple anchors to be installed simultaneously. Unlike re-bend systems where bar length, spacing and diameter are restricted by physical box dimensions, KSN Anchors provide total design flexibility.
Ancon Low Thermal Conductivity Wall Ties
Leviat
The Ancon range of low thermal conductivity wall ties minimise heat loss through thermal bridging, improving the energy efficiency of a masonry cavity wall. The use of these ties can reduce insulation depth and wall footprint.
In addition to a number of stainless steel wire wall ties, the range includes the Ancon Teplo range which is manufactured from pultruded basalt fibres set in resin. This BBA-approved product is available exclusively from Leviat. It has a thermal conductivity of just 0.7W/mK, making it the most thermally efficient wall tie on the market.
Ancon Staifix Complete Guide to Wall Ties and Restraint Fixings
Leviat
Wall ties are an important element in the stability of cavity walls. The correct selection, spacing and installation of ties is essential to avoid damp penetration and the distortion or cracking of brickwork. Leviat can advise on the correct fixing to suit your project and provide details of your nearest stockist.
Ancon Thermal Breaks
Leviat
Masonry support systems from Leviat can now be supplied with Thermal Breaks to minimise heat loss through cold bridging and improve the energy efficiency of the building envelope.
Ancon Thermal Breaks are manufactured from a durable fibre-reinforced thermoset plastic which combines low thermal conductivity with high compressive strength. They are shaped like a standard Ancon key-hole shim in order to locate quickly and easily, between bracket and structural frame, as a support system is installed.
Ancon Thermal Windposts (TWP2)
Leviat
The patented new Ancon Thermal Windpost (TWP2) from Leviat has been designed to minimise thermal bridging in masonry cavity walls, offering up to an impressive 70% reduction in thermal transmission through the span of the windpost.
CB Coupler Box and CS Coupler Strip Reinforcement Continuity Systems
Leviat
Ancon CB Coupler Boxes simplify the continuity of reinforcement at concrete construction joints. They allow engineers to design slab-to-wall connections without the traditional restrictions on bar length and bar diameter of re-bend/pull-out continuity systems and help contractors to eliminate manual bar straightening on site.
Channel, Bolts and Fixings
Leviat
There are various methods of fixing stainless steel masonry supports, restraints and windposts to either concrete or steel frames.
The selection of the most appropriate method will depend on many factors including fixing centres, edge distances, type of fixture, loading and the site adjustment required.
Corner Guards
Leviat
Corner Guards offer protection to exposed edges of columns and walls in areas of high traffic such as car parks, warehouses, hospitals etc.
Ancon manufactures corner guards in a standard length of 1250mm in either stainless steel, galvanised steel or untreated mild steel.
Design of Shear Connections using KSN Anchor Box
Leviat
Ancons internally threaded KSN Anchors, supplied in a metal casing and used in combination with Bartec Plus parallel-threaded reinforcing bars, can now be detailed in a single row along the slab section centreline. The innovative KSN Anchor Box provides a cost-effective design solution that minimises rebar congestion in both the slab and the wall, simplifies bar scheduling and is quick and easy to install with no requirement for manual bar straightening on site.
E-HLD Shear Load Connectors
Leviat
The Ancon E-HLD joins new concrete slabs to existing concrete walls. It is designed to transfer shear load where new slabs are connected to diaphragm walls or secant pile walls in basement construction.
Eazistrip Reinforcement Continuity Systems
Leviat
The Eazistrip Reinforcement Continuity System is a quick and easy to install method of maintaining continuity of reinforcement at construction joints in concrete. It consists of a galvanised steel casing with a dimpled surface to provide an effective concrete bond.
Pre-bent bars are housed within the casing and are enclosed by a protective cover. Each end of the unit is sealed with a polystyrene block in order to prevent the ingress of concrete.
Engineered Fixing Solutions for Tunnels
Leviat
Due to its long-life, low-maintenance characteristics, stainless
steel offers whole-life costing benefits. Ancon has a wealth of
experience of working with a variety of material types and
grades, specialising in the fabrication of Austenitic, Duplex and
Super Duplex stainless steels. Ancon can advise on the
selection of the most suitable material for any fabrication
Gauge Tape
Leviat
Ancon Gauge Tape provides a visual reference that aids accurate coursing and improves the quality of the external finish. Use of the tape can also accelerate the speed of construction. It allows frame cramps to be fixed at accurate vertical centres for the full height of an elevation in advance of the masonry being built.
Halfen HIT Insulated Balcony Connector System
Leviat
Halfen HIT is a high performance structural connection system which can now be used to join post tensioned concrete balconies to a post tensioned concrete slab. The system is suitable for use with all types of proprietary bonded and unbonded post tensioning systems currently available on the market.
The Halfen HIT Post Tensioned Balcony Connector system, which incorporates our established Halfen HIT Structural Thermal Break, allows balconies to be cast together with the main slab and then simultaneously tensioned. Formwork installation and removal on balconies and the main slab can therefore take place at the same time, driving significant efficiencies on construction sites and enabling a faster, more efficient build programme.
Helical Nails for Warm Roof Construction
Leviat
Helical nails from Ancon Building Products are quick and reliable fixings for use in warm roof applications. Unlike traditional nails, they rotate as they are driven in, inducing a self-tapping action and consequently do not split timbers or compress the layer of insulation.
Ancon supplies fixing solutions for both pitched and flat roofs.
Isotec Thermally Insulated Balcony Connectors
Leviat
Ancon Isotec is a high performance thermal break system for concrete-concrete balcony applications, comprising 100% stainless steel reinforcement and fire-resistant mineral wool insulation. It is particularly suitable for highly energy-efficient structures and compression studs facilitate installation in heavily congested or stepped floor slabs where compression bars would be difficult to accommodate.
Lockable Dowels for Temporary Movement Joints
Leviat
Lockable Dowels have been designed by Ancon for use at temporary movement joints, most commonly found in post-tensioned concrete frames.
These dowels allow initial shrinkage of the concrete to take place and are then locked in position with a mechanical plate and a controlled amount of epoxy resin. The locked dowels continue to transfer shear, but prevent further movement taking place.
Masonry Reinforcement and Windposts
Leviat
Large panels of masonry or panels with openings can often be difficult to justify structurally. The traditional solutions have been to either increase the thickness of the wall or introduce an additional masonry pier.
Ancon AMR Bed Joint
Reinforcement and Ancon
Windposts are designed to provide
additional lateral support for panels
of masonry. Windposts can be
installed into either the inner leaf of
blockwork or into the cavity leaving
the blockwork undisturbed. Ancon
AMR is a fabricated and flattened
stainless steel or carbon steel
reinforcement which locates in the
bed joint to strengthen a wall.
Parapet Posts are used as vertical
support for brickwork in parapet
panels.
Masonry Support Systems and Lintels
Leviat
Masonry cladding on steel or concrete framed structures is normally supported by stainless steel support systems.
Frame type, differential movement, type of cladding, masonry load and cavity width all need to be considered when designing the most appropriate fixing solution.
NEXUS Next Generation Brick Faced Support System
Leviat
Deep reveals and soffits are an increasingly popular design feature that add an extra depth and dimension to masonry façades.
With the new Nexus® system, creating perfect brick faced soffits couldn’t be easier. The advanced design units are lightweight and easy to fit, and can be simply aligned using a unique two-part system to create a flawless joint with the main brickwork façade – with no unsightly supporting steelwork left exposed.
Developed by two of the building industry’s leading manufacturers, Ibstock Kevington and Ancon, the system combines a high integrity stainless steel brickwork support system with prefabricated brick faced units that can be simply lifted and bolted into position by hand – without mechanical lifting equipment.
Non-Drill Fixings
Leviat
Ancon’s range of ‘NON-DRILL’ masonry-to-steel fixing solutions was developed to address the safety concerns of the Industry.
Driven by customer demand for masonry restraint fixings with an alternate installation method from either shot-firing or drilling, Ancon engineered the six innovative solutions detailed in this brochure.
These new fixings do not require the use of
power tools and can reduce installation times and costs. In all instances they simply abut the column or attach to the flange to restrain the wall against lateral
wind loads.
Product Overview: UK & Ireland Edition
Leviat
Leviat is a world leader in connecting, fixing, lifting
and anchoring technology. From the build of new
schools, hospitals, homes and infrastructure, to the repair
and maintenance of heritage structures, our engineering
skills are making a difference around the world.
Discover our range of branded products.
Reinforcing Bar Couplers
Leviat
For many years the use of mechanical couplers to join reinforcing bars has been regarded as a means of reducing the use of long bars. Engineers and contractors now recognise the benefits of using couplers to accelerate the speed of construction, increase productivity and simplify design details.
The Ancon range of reinforcing bar couplers is the most comprehensive available and includes tapered threaded, parallel threaded and mechanically bolted couplers.
Reinforcing Large Format Stack-Bonded Masonry - Ancon AMR Masonry Reinforcement
Leviat
Where large format masonry units are stacked one above the other, the lack of bonding between them will greatly reduce the overall flexural strength of the panel and the ability of the wall to spread vertical loads.
Ancon AMR Masonry Reinforcement, located in the bed joints, will increase the panel’s flexural strength and improve the capacity to resist lateral loads and spread vertical loads.
Shear Load Connectors
Leviat
Ancon connectors can be used for movement joints in floor slabs, suspended slabs, and for replacing double columns and beams at structural movement joints. Applications in civil engineering include joints in bridge parapets, bridge abutments and diaphragm wall construction.
Shearfix Punching Shear Reinforcement
Leviat
Used within a slab to provide additional reinforcement around columns, Ancon Shearfix is the ideal solution to the design and construction problems associated with punching shear. The system consists of double-headed studs welded to flat rails, positioned around the column head or base.
Special Fabrications in Stainless Steel
Leviat
Ancon designs and manufactures high integrity steel components for a wide range of industries including Civil Engineering, Building, Infrastructure, Water Treatment, Nuclear and Mining.
Ancon has a wealth of experience of working with a variety of material grades and boasts an impressive project portfolio. The company has the capability to fabricate all Austenitic, Duplex and Super Duplex stainless steels in a plate thickness of up to 30mm.
All fabrication work is designed and manufactured to suit individual customer requirements and large stocks of stainless steel are maintained in order to meet urgent deliveries.
SSTC/STC Thermally Insulated Balcony Connectors
Leviat
Ancon STC and SSTC steel-to-concrete balcony connectors are used to anchor steel balconies to concrete floor slabs and have been proven through thermal modelling to reduce heat loss when compared to direct connections.
The two-part assembly, comprising a cast-in anchorage and a post-fixed bracket with thermal pad located at the interface, allows for phased construction. Unlike one-piece systems which must be left exposed on-site for some time, the Ancon bracket component is not fixed until required, reducing the risk of damage.
SSTS/STS Thermally Insulated Balcony Connectors
Leviat
Ancon STS (galvanised steel) and SSTS (stainless steel) are compact thermal breaks, typically used for connecting steel balconies to structural steel frames. They are also equally suitable for other steel-to-steel applications.
Staifix Cavity Wall Ties
Leviat
Wall ties for use in external cavity walls should be selected by the 'Types' in PD6697. This document classifies wall ties by strength and use. Wall ties for use in internal separating walls should comply with Approved Document E: Resistance to the passage of sound.
Staifix-Thor Helical Crack Stitching Kit
Leviat
This kit contains all the necessary components to permanently repair vertical or stepped cracks in masonry. Experts in the remedial market have designed the kit’s contents, guaranteeing the correct specification of reinforcing bar, grout and installation tools required for this application and the compatibility of all components.
Starter Bar Systems
Leviat
The Ancon Starter Bar system is designed to increase the speed of construction at joints where continuity of reinforcement is required, or for fixing applications using standard metric bolts or studding. Use of this Ancon system can simplify concrete design and eliminate the need to drill formwork or concrete.
