The BASWA Basic panel has enhanced impact resistance and is thus suitable for wall applications. As panel joints do not need to be grouted, installation time is also faster compared to BASWA Phon. The system is finished with smooth, seamless marble plaster coatings from BASWA.

Small bore water-bearing capillary tube mats are installed beneath the smooth BASWA Phon surface, creating draught-free and silent room temperature control with excellent sound absorption. Excellent cooling and radiant heating capacities are attained due to the highly conductive marble acoustic plaster, as well as the good thermal insulation of the glass fibre acoustic panels. Properties: Excellent broadband sound absorption Cooling capacity at t = 8 K: 79 W/m2 (according to DIN EN 14240 : 2004-04) Heating capacity at t = 15 K: 117 W/m2 (according to DIN EN 14037-2) Minimum installation height Smooth seamless surfaces Extensive range of colours (NCS/RAL) Building material class B-s1-d0 according to DIN EN 13501-1

BASWA Natural utilises sustainable and organically grown plant fibres in the acoustic panel and provides high performance sound absorption with a smooth seamless plastered finish. The marble plaster coating options are trowel applied for a discreet architectural appearance.

BASWA acoustic plaster systems are used to reduce reverberation time whilst maintaining a discrete appearance. The standard BASWA Phon system consists of two elements: the pre-coated acoustic panel that is adhered to a stable, airtight substrate such as plasterboard or concrete; and the smooth trowelled marble surface coating. The microporous surface coatings are seamlessly coated in single or double layer coatings, depending on the design and acoustic requirement. Due to the combination of high acoustic absorption (up to Class A) and timeless aesthetics, BASWA Phon creates new design possibilities for architects and acousticians.

BASWA Core is an acoustically absorptive lining with a smooth seamless finish, and is thermally conductive for use with thermally activated substrates (TAC).
