Compare

TVS Soft - Acoustic ceiling tile

Name: TVS Soft - Acoustic ceiling tile
Brand: Total Vibration Solutions Limited t/a TVS Group
SKU: 78U3M6kjECPfcu7WYrWwCR

Verified by manufacturer 6 months ago

Total Vibration Solutions Limited t/a TVS Group

Acoustic soft fibre ceiling tile providing Class A absorption.

Jump to:

+44 (0)1706 260 220 Website

Application

Widely used in more sound-sensitive areas such as:

SEN rooms.
Drama rooms.
Offices.
Cinemas.

Description

TVS Acoustic Soft ceiling tile is a soft fibre tile providing a Class A absorption, making it particularly suitable for sound-sensitive areas.

Features and benefits:

Stone wool substrate with monolithic visual reducing installation time.
Exceptional sound absorption.
High light reflectance reduces light fixtures and energy use.
Soft fibre ceiling tile.
25 dB attenuation.
99% RH moisture resistant.
Washable and scrubbable finish.
Impact and scratch resistant.
Available in plank sizes compatible with Logix Integrated Ceiling System.
Available in baffle sizes.
Soft fibre substrate is inherently resistant to the growth of mould and mildew (as per ASTM D3273).
Meets the requirements in accordance with ASTM E1264.

General information

Color	White Grey Yellow Green Blue Red Black Show more
Finish	Painted
Material	Stone wool Fibre
Shape	Square
Length	600 mm
Width	600 mm
Height	15 mm
Warranty description	Two year

Uniclass	Pr_35_93_13_80 Sound attenuator infill unitsPrimary
CAWS	K40/10 Unit/ modular suspended ceilings K40/265 Infill units K40/115 Unit/ modular suspended ceiling system

Specification data - Sound attenuator infill units

Standard	To ASTM E1264.
Form	Infill unit.
Rigidity	Rigid.
Application	Ceiling mounting.
Material	Stone wool substrate.
Material density	1.5 kg/m².
Acoustic performance	-
Purpose	Absorber.
Sound absorption	Class A.
Dimensions	-
Size (length x width)	600 x 600 mm.
Thickness (overall)	19 mm.
Edges	Square.
Surface pattern	G.
Finish	Painted. Guidance for specification option: Painted fiberglass scrim.
Colour	White. Light Grey. Dark Grey. Yellow. Green. Blue. Red. Black.

Noise reduction coefficient (NRC)	0.90.
Ceiling attenuation class	25 dB.
RelativeHumidity	99% (maximum).
Light reflectance	88%.
Thermal resistance	0.6 m² °K/W – R 2.6.
Smoke classification	Class A, Flame Spread, 10; Smoke development, 10.

Sustainability data

Contains Red List materials	No
Country of material origin	Turkey
Country of product manufacture	Turkey
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	0 kg CO₂ eq/unit
Recycled content As defined in clause 7.8 of BS EN ISO 14021	47 %
