Verified by manufacturer 20 days ago
12 mm TVS ABSorb Baffle
Lightweight and semi-rigid acoustic baffle panel.
TVS ABsorb Baffle is a lightweight and semi-rigid panel that has sound-absorbing properties. Designed with solid colour throughout, TVS ABSorb Baffle has the potential to be used in a large array of spatial design and interior solutions. More than just a traditional interior acoustic panel, the baffle can be employed as a base material for creative solutions where design and aesthetics are important. The panels are made from 100% polyester and manufactured in the UK. Containing a minimum of 65% post-consumer recycled material, TVS ABSorb Baffle is completely safe, non-toxic, non-allergenic and non-irritant.
Features and benefits:
Color | White Grey Cream Beige Green |
Finish | Other |
Material | Polyester fibre (PET) |
Shape | Rectangle |
Length | 2400 mm |
Width | 1200 mm |
Height | 12 mm 24 mm |
Uniclass | |
CAWS | K13/170 Acoustic panel lining K13/170 Acoustic panel lining |
Standard | Manufactured under ISO 9001 and ISO 14001 accredited Quality and Environment System. |
Form | Baffle. |
Rigidity | Semi-rigid. |
Application | Ceiling mounting.Soffit mounting.Wall mounting. |
Material | Polyester Fibre (PET). |
Material density | 200 kg/m³. |
Acoustic performance | |
Purpose | Absorber. |
Sound absorption | Manufacturer guidance
|
Fire performance | |
Reaction to fire | To EN13501-1, B-s2,d2.Guidance for specification option:
|
VOC emissions | Certified low VOC.Guidance for specification option: Consult manufacturer for details. |
Dimensions | |
Size (length x width) | 2400 x 1200 mm. |
Thickness (overall) | 12 mm. |
Colour | Pavillion.Savoye.Opera.Acros.Falling water.Pinnacle.Senado.Bosco.Zenith.Ironbank.Flatiron.Empire.Petronas. |
Noise reduction coefficient (NRC) | 0.45 (minimum). Guidance for specification option: Consult manufacturer's literature for details. |
Weight | 2400 g/m² (+/– 10%). |
Contains Red List materials | No |
Country of material origin | France |
Country of product manufacture | France |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 65 % Guidance for specification option: Manufactured using a minimum of 65% post-consumer recycled material. |
