Technishield 50 Double Door

Verified by manufacturer 14 days ago

Optima Third party certifications:
  • BM Trada

    BM Trada

    Certificate type

Fire-rated glass double door doorset.

Jump to:
+44 (0)1494 492725 Website

Application

For use in conjunction with Technishield 50 partition system.

Description

A framed, rebated, double-leaf, fire-rated glass doorset on hinges.


Features and benefits:

  • Offering either 30 or 60 minutes' integrity.
  • Part M-compliant clear opening included.

General information

Color

White

Silver

Other

Finish

Powder-coated

Material

Glass

Stainless steel

Steel

Warranty description

Three year

Guidance for specification option:

See Warranty Policy literature for more details.

Uniclass

Ss_25_30_20_25 Doorset systemsPrimary

CAWS

L20/480 Doorsets

L20/55 Doorsets

Product range

Fire Range
Doorsets

Specification data - Doorset systems

System performance

Fire performance.

Doorset

-

Type

Fire rated glass doorset.

Seals or inserts

-

Door

Manufacturer's standard.

Guidance for specification option:

Dropseal:

Type RO drop seals.

Door seals:

Two face-fitted, weld-on hinges per leaf.

Over panels

Not required.

Over panel.

Over panel and side panel.

Guidance for specification option:

Insert requirements.

Side panels

Not required.

Side panel both sides.

Side panel left side.

Side panel right side.

Over panel and side panel.

Guidance for specification option:

Insert requirements.

Hardware

Manufacturer's standard.

Guidance for specification option:

Hinges:

Three face-fitted, weld-on hinges per leaf.

Handles:

Forster stainless steel lever handle set, fire-rated, cranked U-form steel cored with 9 mm spindle.

Lock:

Two-point fire-rated lever latch with Euro-cylinder operated deadlock.

Slave door lock:

Self-locking drive bolt, two-point.

Euro cylinder:

Cylinder and turn – 35 mm/ 35 mm.

Door closer:

TS-93 2-4.

Other.

Guidance for specification option:

Insert requirements; contact manufacturer for information.

System accessories

Not required.

Required

Guidance for specification option:

Insert requirements; Forster stainless steel lever handle set, fire-rated, cranked U-form steel cored with 9 mm spindle.

Samples required

Not required.

Required.

FireRating

E30.

Guidance for specification option:

30 minutes' integrity (30/0).

E60.

Guidance for specification option:

60 minutes' integrity (60/0).

Finish/ Colour

Powder-coated, RAL.

Guidance for specification option:

Insert requirement; contact manufacturer for more information.

Powder-coated, RAL 9006 Silver.

Guidance for specification option:

50 microns, 30% gloss (nominal).

Powder-coated, RAL 9010 White.

Guidance for specification option:

50 microns, 30% gloss (nominal).

Manifestation

Guidance for specification option:

Insert requirements.

Size

Guidance for specification option:

  • Door: With over-panel: Available 1850–2800 x 2200–4000 mm (w x h); without over-panel: Available 1850–2800 x 1800–2900 mm (w x h). All dimensions subject to specification and certification.
  • Side panel: Available 300–1100 mm in width.


Configuration

As schedule.

As drawing.

Guidance for specification option:

Insert drawing reference number.

Sustainability data

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

149 kg CO₂ eq/m²

Guidance for specification option:

See Environmental Product Declaration literature for LCA data.

BIM objects

Platform Compatible Version
Revit
-

1

Third party certifications

BM Trada

BM Trada

009109 (3) - ISO 14001 - Optima Products Limited
