30/0 or 60/0 Technishield 50 Non-rebated, Fire Resistant Double Glazed Door

Name: 30/0 or 60/0 Technishield 50 Non-rebated, Fire Resistant Double Glazed Door
Brand: Optima
SKU: k6vauF3uaffYGA4TxPxSMJ

Verified by manufacturer 2 days ago

Optima

Fire resistant glass doorset, non-rebated. 30 or 60 minutes integrity

Jump to:

+44 (0)1494 492725 Website

Application

For use in conjunction with Technishield 50 partition system.

Description

A framed, double-leaf, non-rebated, fire resistant glass doorset on hinges.

Features and benefits:

Offering either 30 or 60 minutes' integrity.
Part M-compliant clear opening included.

General information

Color	Silver White Other
Finish	Powder-coated
Material	Glass Stainless steel Steel
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Three year Guidance for specification option: See Warranty Policy literature for more details.

Uniclass	Ss_25_30_20_25 Doorset systemsPrimary
CAWS	L20/480 Doorsets L20/55 Doorsets

Product range	Technishield 50 Fire Range

Specification data - Doorset systems

Classification data
System performance	Fire performance.
Doorset	-
Type	Double leaf fire rated glass doorset.
Seals or inserts	-
Door	Manufacturer's standard. Guidance for specification option: Dropseal: Type RO drop seals. Door seals: Fire and smoke protection double-seal.
Over panels	Not required. Over panel. Over panel and side panel. Guidance for specification option: Insert requirements.
Side panels	Not required. Side panel both sides. Side panel left side. Side panel right side. Over panel and side panel. Guidance for specification option: Insert requirements.
Hardware	Manufacturer's standard. Guidance for specification option: Hinges: Two face-fitted, weld-on hinges per leaf. Handles: Forster stainless steel cranked pull handles Lock: Not available. Slave door lock: Not applicable. Euro cylinder: Not applicable. Door closer: TS-93 2-4. Other. Guidance for specification option: Insert requirements; contact manufacturer for information.
Samples required	Not required. Required.
FireRating	E30. Guidance for specification option: 30 minutes' integrity (30/0). E60. Guidance for specification option: 60 minutes' integrity (60/0).
Finish/ Colour	Powder-coated, RAL. Guidance for specification option: Insert requirement; contact manufacturer for more information. Powder-coated, RAL 9006 Silver. Guidance for specification option: 50 microns, 30% gloss (nominal). Powder-coated, RAL 9010 White. Guidance for specification option: 50 microns, 30% gloss (nominal).
Manifestation	Guidance for specification option: Insert requirements.
Size	Guidance for specification option: Door: With over-panel: Available 1850–2800 x 2200–4000 mm (w x h); without over-panel: Available 1850–2500 x 1800–2625 mm (w x h). All dimensions subject to specification and certification. Side panel: Available 300–1100 mm in width.
Configuration	As schedule. As drawing. Guidance for specification option: Insert drawing refernece number.

Sustainability data

Country of product manufacture	United Kingdom
Material	Glass Stainless steel Steel
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Self-declared
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 149 Value guidance: A1-A3 See Environmental Product Declaration literature for LCA data.
