SitaEasy Go Parapet Rainwater Outlet - Parapet Outlet

Name: SitaEasy Go Parapet Rainwater Outlet - Parapet Outlet
Brand: Sita Bauelemente GmbH
SKU: wETynWZWxHLjVrF6Fa5sZJ

Verified by manufacturer 3 months ago

DN70

Third party certifications:

Thermally insulated parapet outlet, for main and emergency drainage through the parapet.

Jump to:

BOS

Application

For main drainage on flat and slightly pitched, used and unused roof surfaces.

For direct connection of pipes with plug-in coupler, for conventional drainage.

Thermally insulated parapet outlet made of polyurethane, for main and emergency drainage through the parapet.

Features and benefits:

Not sensitive to the weather (UV/ IR radiation, rain/ snow, temperature, ozone, etc.).
Sizes DN 70 and 100.
Impact and shock resistant.
Durable.

Color	Black Beige
Material	Polyurethane (PUR) Bitumen Guidance for specification option: Sleeves only. PVC Thermoplastic elastomer (TPE) Thermoplastic polyolefin (TPO)
Shape	Circle Rectangle Square
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Six year

Uniclass	Pr_65_50_35_37 Gravity rainwater outletsPrimary
CAWS	R10/26 Proprietary rainwater outlets R10/365 Proprietary rainwater outlets

Roof construction	-
Form	Guidance for specification option: Insert details.
Material	Body: Rigid polyurethane integral foam. Sleeve: Bitumen.
Grating	Not applicable.
Spigots	DN70, outer diameter 75 mm. Guidance for specification option: Pipe connection (support) length: 55 mm. Opening/ core borehole: 140 mm. Manufacturer guidance Discharge rate 0.7 L/s as waterspout at 35 mm retaining height. Consult manufacturer's literature for further details.
Integral accessories	Bitumen sleeve; fixing ring. Guidance for specification option: Fixing ring for addition securing of the connection sleeve and to hold a dome grate; see Accessories.

Orientation	Horizontal (through parapet).
Accessories	None. SitaEasy Go dome grate. SitaMore vapour barrier plate (1 x DN70). SitaMore vapour barrier plate (2 x DN70). SikaAttika cladding cover plate. SitaMore sealing sleeve. Show more
Reaction to fire	Euroclass E/ B2 normal flammability.

Country of material origin	Germany
Country of product manufacture	Germany
Material	Polyurethane (PUR) Bitumen Guidance for specification option: Sleeves only. PVC Thermoplastic elastomer (TPE) Thermoplastic polyolefin (TPO)
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	13.4 kg CO₂ eq/unit
