Ray - Carpet Tiles

Name: Ray - Carpet Tiles
Brand: Modulyss
SKU: cMUYVFCSvgA1zvGsoV4SXi

Verified by manufacturer 3 days ago

Product certifications:

Ray is a loop pile carpet tile with a soft linear pattern and tonal gradients that guide flow and define zones.

Jump to:

Application

Suitable for commercial applications and high traffic areas.

Ray is a multi-level loop pile carpet tile with a linear, dotted organic pattern that flows naturally across the floor.

Features and benefits:

Tonal gradients to create soft movement and a visual rhythm that enhances the way people experience a space.
Ideal for guiding flow, defining zones or supporting wayfinding in dynamic environments.
Crafted from low-carbon Thrive matter recycled nylon and backed by ecoBACK PLUS.
Cradle to Cradle Certified® Silver under version 4.0.
Available in 16 colour options.

Color	Beige Blue Bronze Brown Copper Cream Green Grey Orange Purple Yellow Show more
Finish	Tufted
Material	Nylon Guidance for specification option: Crafted from low-carbon Thrive matter recycled nylon.
Shape	Square
Length	500 mm
Width	500 mm
Height	6.5 mm
Warranty description	15 year

Uniclass	Pr_35_57_11_62 Pile carpet tilesPrimary
CAWS	M50/15 Carpet tiling M50/130 Carpet tiling

Classification data
Product reference	Ray.
Style	Loop pile.
Material	Thrive matter yarn.
Classification	-
Standard	To BS EN 1307.
Third-party certification	Cradle to Cradle Certified® Silver.
Level of use class	To BS EN 1307, Class 33.
Luxury rating class	LC2.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	90%.
Size	500 x 500 mm.
Colour and pattern	Ray 140. Ray 398. Ray 447. Ray 514. Ray 528. Ray 542. Ray 651. Ray 605. Ray 766. Ray 912. Ray 945. Ray 950. Ray 957. Ray 967. Ray 982. Ray 986.
Total weight	3.100 g/m².
Pile weight	715 g/m².
Total height	6.5 mm.
Height	3.5 mm.
Tuft density	176.000 /m².
Castor chair rating	A : continuous use.
Fire resistance	To EN 13501-1, Bfl-s1.
Light fastness (to BS EN ISO 105 B02)	≥7.
Colour fast - rubbing	≥4.
Thermal resistance	To ISO 8302, 0.08 m²K/W.
Impact sound reduction	To ISO 10140, ΔLw: 25 dB.
Antistatic properties	To ISO 6356, ≤ 2 kV.
Dimensional stability	To BS EN 986, max. 0.2%.
Sound absorption	To ISO 354, αw: 0.15.

Contains Red List materials	No
Country of material origin	Europe
Country of product manufacture	Belgium
Material	Nylon Guidance for specification option: Crafted from low-carbon Thrive matter recycled nylon.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	90 %
