Metallic Appearance on a Flexible Roofing Membrane - RENOLIT ALKORPLAN Metallics - Laminated Membrane

Name: Metallic Appearance on a Flexible Roofing Membrane - RENOLIT ALKORPLAN Metallics - Laminated Membrane
Brand: RENOLIT UK Ltd
SKU: onHqpiqSBCr5PikEM6ijgm

Verified by manufacturer 5 months ago

RENOLIT UK Ltd

Third party certifications:

BBA Agrément Certificate
Certificate type
EPD
Certificate type

High performing flexible membrane for visible and pitched roofs, giving both functional and aesthetically pleasing effects of metallic silver and copper.

Jump to:

+44 (0)1670 718283 Website

Application

Mechanical fastening is suited for lightweight, metal deck structures, for large industrial buildings, warehouses, logistic centers, etc. It can also be applied on concrete structures or wooden decks.

The roofing membrane is fastened to the substrate along the longitudinal edges by means of pressure plates and screws. Wind load calculations can accurately determine the exact number of fasteners to be used in order to avoid any risk of wind uplift.

At the overlap, the membrane is hot air welded. The hot air welded joints are at least as strong as the roofing membrane itself. Quick and easy to apply, in all weather conditions, the system provides a durable watertightness of the roof.

Description

With RENOLIT ALKORPLAN Metallics, RENOLIT offers flexible, high performing and functional roofing membranes with a metallic (aluminium/silver and copper) appearance.

The silver and copper finish, makes these roofing membranes exceptionally well suited to visible/pitched roofs (minimum pitch 30 mm/m).

The roofing membranes are provided with a clearcoat. This is a transparent protective layer applied during the production process. The clearcoat makes it harder for dirt to adhere to the roofing membrane, and facilitates cleaning of the membrane with water. The combination of the RENOLIT ALKORPLAN roofing membrane and the clear coat makes the ALKORPLAN Metallics the top products in the RENOLIT roofing membrane range.

Besides the roofing membranes themselves, synthetic standing seam profiles are available in silver and copper which enhance the aesthetically pleasing appearance of the roof even further. Details of the standing seam system can be found in the information on the RENOLIT ALKORPLAN Design range.

Features and benefits:

Mechanically fastened system.
Special embossing included.
Recyclable.
Cheaper than a metallic roof.
Metallic appearance of a metal roof.
It can be combined with RENOLIT ALKORPLAN Design profile.

General information

Color	Copper Guidance for specification option: Metallic. Silver Guidance for specification option: Metallic.
Finish	Embossed
Material	Polyester Guidance for specification option: Woven. Reinforcement. Polyvinyl chloride (PVC) Guidance for specification option: Membrane. Manufacturer guidance Single ply membrane.
Shape	Rectangle
Length	20000 mm
Width	1050 mm
Height	1.5 mm
Warranty description	15 year 20 year Ten year

Uniclass	Pr_25_57_51_66 Polymeric membranesPrimary
CAWS	J42/28 Waterproof membrane J42/400 Waterproof membrane

Specification data - Polymeric membranes

Material	Polyvinyl chloride (PVC).
Standard	To BS EN 13956.
Third-party certification	British Board of Agrément (BBA) certificate.
Integral backing fleece	No.
Width (minimum)	1050 mm.
Thickness (minimum)	1.5 mm.
Colour	Metallic Copper. Metallic Silver.
Accessories	None. RENOLIT ALKORPLAN Design Design profile Standing seam profiles.

Fire rating	Broof (t4) to EN 13501-5.
Installation	Mechanically fixed.
Roll length	20 000 mm.
Additional finish	Embossed metallic finish.
Standard	Conforms to UEAtc guidelines.
Performance characteristics	- Manufacturer guidance Refer to BBA Certificate.

Sustainability data

Country of material origin	Spain
Country of product manufacture	Spain
Material	Polyester Guidance for specification option: Woven. Reinforcement. Polyvinyl chloride (PVC) Guidance for specification option: Membrane. Manufacturer guidance Single ply membrane.
