Name: Manufactured Brick Slips
Brand: Wienerberger Ltd
SKU: nMRGMNN1AJVCwYkreFcKgP

Description

Wienerberger’s manufactured clay brick slips are a high-quality brick slip offering extremely high levels of consistency throughout the build process. Manufactured extruded brick slips conform to EN14411 achieving both tight tolerances and low water absorption, which is ideal for both off-site and on-site installations. The slips are not produced by cutting from traditional bricks but are instead purpose made to precise dimensions meaning a significant wastage saving is achieved in comparison to cut brick slips. Due to this production method the amount of natural resources consumed per square metre of façade is reduced.

Features and benefits:

Three profiles - brick slip, corner return and soffit return.
Smooth, sanded, rustic and waterstruck textures.
Available in 9 mm or 14 mm thickness.
42 different colour options.
Slips conform to BS EN 14411.
Low water absorption (less than 3%).
A1 fire classification in accordance with BS EN 13501-1.
Suitable for internal and external use.
Bespoke colours and blends available to order upon request.

General information

Color	Orange Guidance for specification option: 12280 terra-natural smooth 27000 buff-orange multi smooth Black Guidance for specification option: 92900 black-grey-brown smooth Blue Guidance for specification option: 93800 blue-blue multi smooth 93700 blue brown coal brindled smooth Brown Guidance for specification option: 94180 brown-grey multi smooth 92800 brown-grey multi smooth 92905 brown–orange coal brindled smooth Grey Guidance for specification option: 60003 grey multi smooth Red Guidance for specification option: 13000 red natural smooth 14000 red multi smooth 13050 red creased 14500 red flashed smooth 13090 red creased sanded 14590 red flashed creased sanded 86305 red-orange coal brindled smooth 13392 red multi clamp fired creased sanded 13302 red multi clamp fired smooth 15600 red blue multi smooth 14050 red multi creasedf 16000 red heavy multi smooth Other Guidance for specification option: 25600 natural yellow smooth 29000 leather natural multi smooth 29050 leather natural multi creased 26000 buff multi smooth 24000 autumn leaf smooth 14090 red multi creased sanded 33250 bordeaux creased Show more Manufacturer guidance TBC
Finish	Smooth Sanded Waterstruck Creased
Material	Clay
Shape	Rectangle
Length	215 mm
Width	9 mm
Height	65 mm

Uniclass	Pr_20_93_52_15 Clay bricksPrimary Pr_35_93_96_19 Ceramic tiles
CAWS	F10/110 Clay facing brickwork F10/5 Facing brickwork

Literature

Manufactured Brick Slip Brochure

Standard	To BS EN 14411.
Brick description	Extruded brick slip.
Appearance	Smooth. Sanded. Rustic. Waterstruck.
Work size (length x width x height)	215 x 65 mm. 215 x 102 mm.
Water absorption	<3%. Guidance for specification option: Passed EN ISO 10545-3.
Reaction to fire	Class A1 to BS EN 13501-1.

Dry weight	0.30 kg each/18 kg per m². Guidance for specification option: 9 mm. 0.44 kg each/26.4 kg per m². Guidance for specification option: 14 mm.
Thickness	9 mm. 14 mm.

Country of material origin	Germany
Country of product manufacture	Germany
Material	Clay

Manufactured Brick Slips

Application

Description

General information

Color

Manufacturer guidance

Finish

Material

Shape

Length

Width

Height

Uniclass

CAWS

Specification data - Clay bricks

Standard

To BS EN 14411.

Brick description

Extruded brick slip.

Appearance

Smooth.

Sanded.

Rustic.

Waterstruck.

Work size (length x width x height)

215 x 65 mm.

215 x 102 mm.

Water absorption

<3%.

Reaction to fire

Class A1 to BS EN 13501-1.

Dry weight

Thickness

Sustainability data

Country of material origin

Country of product manufacture

Material

Literature
